TOOL-CM25-1
Rennsteig Crimping Machine CM 25-1
Images shown may represent a range of products or be for illustration purposes only.
Kit Contents:
Crimp machine without die set
OEM P/N:636 025-1 RT
- Accepts any of the hundreds of different PEW 12 system crimp dies and locators*
- User friendly rotatable die position
- Stroke from 6 to 14mm (0.24 - 0.55")
- Automatic safety closure - needed only for 14mm (0.55") stroke
- Digital crimp counter
- Hand or foot switch
- Adjustable leg height
- Operating pressure: 6 BAR (87 PSI)
- Height: 500mm (20") Width: 280mm (11") Depth: 325mm (13")
- Weight: 34kg (74 lbs)
Documents
User Manual (CM25-1-OM.pdf)
