/16-10AWG
10 AWG MIL-W-22759/16-10 Wire
SPECS:
- 5.0 mm2 (10 AWG) (4.77 mm2 calculated)
- 37/26 stranding
- Nom. O.D. 3.53 mm (0.139 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 30.9A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/16-12AWG
12 AWG MIL-W-22759/16-12 Wire
SPECS:
- 3.0 mm2 (12 AWG) (2.99 mm2 calculated)
- 37/28 stranding
- Nom. O.D. 2.89 mm (0.114 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 23.2A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/16-14AWG
14 AWG MIL-W-22759/16-14 Wire
Dimensionally comparable to 2.0 AVSS wire, but with M22759/16 performance.
SPECS:
SPECS:
- 2.0 mm2 (14 AWG) (1.94 mm2 calculated)
- 19/27 stranding
- Nom. O.D. 2.36 mm (0.093 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 17.5A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/16-16AWG
16 AWG MIL-W-22759/16-16 Wire
Dimensionally comparable to 1.25 AVSS wire, but with M22759/16 performance.
SPECS:
SPECS:
- 1.25 mm2 (16 AWG) (1.22 mm2 calculated)
- 19/29 stranding
- Nom. O.D. 2.01 mm (0.079 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 12.9A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/16-18AWG
18 AWG MIL-W-22759/16-18 Wire
Dimensionally comparable to 0.85 AVSS wire, but with M22759/16 performance.
SPECS:
SPECS:
- .85 mm2 (18 AWG) (.96 mm2 calculated)
- 19/30 stranding
- Nom. O.D. 1.48 mm (0.058 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 11A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/16-20AWG
20 AWG MIL-W-22759/16-20 Wire
Dimensionally comparable to 0.5 AVSS wire, but with M22759/16 performance.
SPECS:
SPECS:
- .5 mm2 (20 AWG) (.61 mm2 calculated)
- 19/32 stranding
- Nom. O.D. 1.52 mm (0.060 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 8.2A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/16-22AWG
22 AWG MIL-W-22759/16-22 Wire
Dimensionally comparable to 0.3 AVSS wire, but with M22759/16 performance.
SPECS:
SPECS:
- .3 mm2 (22 AWG) (.38 mm2 calculated)
- 19/34 stranding
- Nom. O.D. 1.32 mm (0.052 in)
- Tinned copper conductor
- ETFE Tefzel insulation
- 6.3A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/32-20AWG
20 AWG MIL-W-22759/32-20 Wire
Dimensionally comparable to 0.5 CAVUS wire, but with M22759/32 performance.
Comparable to 55A0111-20, also known as SPEC 55, or 55A wire, which is the marketing name used by TE-Raychem for SAE AS22759/32-20 wire.
SPECS:
Comparable to 55A0111-20, also known as SPEC 55, or 55A wire, which is the marketing name used by TE-Raychem for SAE AS22759/32-20 wire.
SPECS:
- .5 mm2 (20 AWG) (.61 mm2 calculated)
- 19/32 stranding
- Nom. O.D. 1.27 mm (0.050 in)
- Tinned copper conductor
- Cross-linked modified Tefzel insulation (XLETFE)
- 8.2A current rating*
- 600 V voltage rating
- -50° to +150° C temperature rating
/32-24AWG
24 AWG MIL-W-22759/32-24 Wire
Dimensionally comparable to 0.22 CAVUS wire, but with M22759/32 performance.
Comparable to 55A0111-24, also known as SPEC 55, or 55A wire, which is the marketing name used by TE-Raychem for SAE AS22759/32-24 wire.
SPECS:
Comparable to 55A0111-24, also known as SPEC 55, or 55A wire, which is the marketing name used by TE-Raychem for SAE AS22759/32-24 wire.
SPECS:
- .2 mm2 (24 AWG) (.24 mm2 calculated)
- 19/36 stranding
- Nom. O.D. 0.94 mm (0.037 in)
- Tin plated copper
- Cross-linked modified Tefzel insulation (XLETFE)
- 4.8A current rating*
- 600 V voltage rating
- -65° to +150° C temperature rating
/32-26AWG
26 AWG MIL-W-22759/32-26 Wire
Comparable to 55A0111-26, also known as SPEC 55, or 55A wire, which is the marketing name used by TE-Raychem for SAE AS22759/32-26 wire.
SPECS:
SPECS:
- .125 mm2 (26 AWG) (.15 mm2 calculated)
- 19/38 stranding
- Nom. O.D. 0.81 mm (0.032 in)
- Tin plated copper
- Cross-linked modified Tefzel insulation (XLETFE)
- 3.6A current rating*
- 600 V voltage rating
- -65° to +150° C temperature rating
00000
Invoice Payment
Use this form if you need to pay an invoice. Enter the invoice number and total from the invoice.
00000.5
Shipping and Handling
Use this form to pay for shipping and handling surcharges. Complete the form as necessary, then click "Add to Cart".
00001
Part Special Order (ST)
Use this form if you need to pay for a special order part. Enter the part number, terminal/seal size, quantity, then "Add to Cart"
00002
Part Special Order (LARGE/TOOL)
Use this form if you need to pay for a special order part. Enter the part number, terminal/seal size, quantity, then "Add to Cart"
00003
Part Special Order (Terminal/Seal)
Use this form if you need to pay for a special order part. Enter the part number, terminal/seal size, quantity, then "Add to Cart"
00006
Gift Voucher
Use this form to order a Gift Voucher. Enter the amount, who it is for, (optional) special message, and add it to your cart. It will be sent out via email within 24-48 hours.
025/090II-9S-1
9-Way (7+2) Hybrid Kit
Kit Contents: Housing, 7x 025 socket terminals and seals, 2x 090 socket terminals and seals
Mfr: OEM Tokai Rika
Series: 0.64+2.3II (025+090II) Hybrid Sealed Series
OEM P/N: 4F5902-000 (Black, In Stock)
4F5908-000 (Light Gray)
Mating Part: N/A, device only
Kit Contents: Housing, 7x 025 socket terminals and seals, 2x 090 socket terminals and seals
Mfr: OEM Tokai Rika
Series: 0.64+2.3II (025+090II) Hybrid Sealed Series
OEM P/N: 4F5902-000 (Black, In Stock)
4F5908-000 (Light Gray)
Mating Part: N/A, device only
General
- Sealing:Single Wire Sealed
- Number of Ways:9
- Contact Size:Mixed
- Wire Size:0.13 - 2.00 mm2
- Number of Rows:2
- Pitch:Multiple
- Row Spacing:4.9mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:19A
- Voltage Rating:12V DC
Environmental
- Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-12362
025IIU-20PCB
20-Way PCB Header
Kit Contents: PCB header
Mfr: OEM Tokai Rika
Series: 0.64II (025II) Unsealed Series
OEM P/N: 4M2090-0000 (Natural, tin plated)
Mating Part: 025IIU-20S
Kit Contents: PCB header
Mfr: OEM Tokai Rika
Series: 0.64II (025II) Unsealed Series
OEM P/N: 4M2090-0000 (Natural, tin plated)
Mating Part: 025IIU-20S
General
- Sealing:Unsealed
- Number of Ways:20
- Contact Size:0.64mm (.025)
- Number of Rows:2
- Pitch:2.2mm
- Row Spacing:3.0mm
- Numbered Cavities:No
Mechanical
- Contact Type:Pin, flat
- Termination:PCB solder tail
- Housing Material:PBT
- Mounting Style:PCB Board Mount
- TPA:No
- CPA:No
Electrical
- Current Rating[1]:7A
- Voltage Rating:12V DC
Environmental
- Temp Range[2]:-30 - 80 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-12258
025IIU-20S
20-Way Kit
Kit Contents: Housing, 20 socket contacts for 22-20 awg wire
Mfr: OEM Tokai Rika
Series: 0.64II (025II) Unsealed Series
OEM P/N: 4F2060-000 (Natural)
4F2062-000 (Black)
4F2064-000 (Blue) IN STOCK
4F2067-000 (Orange)
4F2068-000 (Light Gray)
Part Name: 12460NQA20F
Mating Part: 025IIU-20PCB
Kit Contents: Housing, 20 socket contacts for 22-20 awg wire
Mfr: OEM Tokai Rika
Series: 0.64II (025II) Unsealed Series
OEM P/N: 4F2060-000 (Natural)
4F2062-000 (Black)
4F2064-000 (Blue) IN STOCK
4F2067-000 (Orange)
4F2068-000 (Light Gray)
Part Name: 12460NQA20F
Mating Part: 025IIU-20PCB
General
- Sealing:Unsealed
- Number of Ways:20
- Contact Size:0.64mm (.025)
- Wire Size:0.13 - 0.50 mm2
- Number of Rows:2
- Pitch:2.2mm
- Row Spacing:3.0mm
- Numbered Cavities:No
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:7A
- Voltage Rating:12V DC
Environmental
- Temp Range[2]:-30 - 80 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-12460
040IIIU-22PCB
22-Way PCB Header
Kit Contents: PCB header
Mfr: OEM Yazaki
Series: 040 III Unsealed Series
OEM P/N: 7382-6100
Mating Part: 040IIIU-22S
Kit Contents: PCB header
Mfr: OEM Yazaki
Series: 040 III Unsealed Series
OEM P/N: 7382-6100
Mating Part: 040IIIU-22S
Mfr Drawing (7382-6100.pdf)General
- Sealing:Unsealed
- Number of Ways:22
- Contact Size:1.0mm (.040)
- Number of Rows:2
- Pitch:2.5mm
- Row Spacing:4.6mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:PCB solder tail
- Housing Material:PBT+GF
- Mounting Style:PCB Board Mount
- TPA:No
- CPA:No
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-30 - 80 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-12030
040IIIU-22S
22-Way Kit
Kit Contents: Housing, 22 socket contacts for 22-20 awg wire
Mfr: OEM Yazaki
Series: 040 III Unsealed Series
OEM P/N: 7283-5834
Mating Part: 7282-5834, 040IIIU-22PCB
Kit Contents: Housing, 22 socket contacts for 22-20 awg wire
Mfr: OEM Yazaki
Series: 040 III Unsealed Series
OEM P/N: 7283-5834
Mating Part: 7282-5834, 040IIIU-22PCB
General
- Sealing:Unsealed
- Number of Ways:22
- Contact Size:1.0mm (.040)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:2
- Pitch:2.5mm
- Row Spacing:4.6mm
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:3A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- Toyota 90980-11915
040IIIU-7S
7-Way Kit
Kit Contents: Housing (4x parts), 7 socket contacts for 22-20 AWG wire
Mfr: OEM Tokai Rika
Series: 1.0III (040III) Unsealed Series
OEM P/N: 4F0730-000x
5pin housing, 5pin retainer, 2pin housing, Cap
4F0730-0010, 4F0730-0020, 4F0730-0030, 4F0730-0040
Mating Part: 4G0720-000x
Kit Contents: Housing (4x parts), 7 socket contacts for 22-20 AWG wire
Mfr: OEM Tokai Rika
Series: 1.0III (040III) Unsealed Series
OEM P/N: 4F0730-000x
5pin housing, 5pin retainer, 2pin housing, Cap
4F0730-0010, 4F0730-0020, 4F0730-0030, 4F0730-0040
Mating Part: 4G0720-000x
General
- Sealing:Unsealed
- Number of Ways:7
- Contact Size:1.0mm (.040)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:3
- Pitch:2.5mm
- Row Spacing:Multiple
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PA66
- Mounting Style:Free hanging
- TPA:Yes, separate/loose item
- CPA:No
Electrical
- Current Rating[1]:3A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- Toyota 90980-12060
- 5pin housing, 5pin retainer, 2pin housing, Cap
- Sumitomo 1300-7573, 6918-1973, 1300-7574, 6911-2070
- Yazaki 7183-6107, 7158-4799, 7183-1171, 7134-8347
040IIIU-PIN
040 III Unsealed Series Pin Contact
Mfr: Aftermarket Yazaki
Series: 040 III Unsealed Series
OEM P/N: 7114-4231-02
Mfr: Aftermarket Yazaki
Series: 040 III Unsealed Series
OEM P/N: 7114-4231-02
For 0.3-0.5 mm2 (22-20 AWG) wire
General
- Sealing:Unsealed
- Contact Size:1.0mm (.040)
- Wire Size:0.30 - 0.50 mm2
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
Electrical
- Current Rating[1]:3A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- KET ST740771-3
- Terminal used in Toyota 82998-12670 (PIN), 82998-12680 (PIN-Au) repair wire
040IIIU-SKT
040 III Unsealed Series Socket Contact
Mfr: OEM Yazaki
Series: 040 III Unsealed Series, and used in Tokai Rika 1.0III (040III) Unsealed Series
OEM P/N: 7116-4231-02
Mfr: OEM Yazaki
Series: 040 III Unsealed Series, and used in Tokai Rika 1.0III (040III) Unsealed Series
OEM P/N: 7116-4231-02
For 0.3-0.5 mm2 (22-20 AWG) wire
General
- Sealing:Unsealed
- Contact Size:1.0mm (.040)
- Wire Size:0.30 - 0.50 mm2
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
Electrical
- Current Rating[1]:3A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- Terminal used in Toyota 82998-12690 (SKT), 82998-12880 (SKT-Au) repair wire
050-5S
5-Way Kit
Kit Contents: Housing, 5 socket contacts for 22-20 awg wire, 5 seals
Mfr: OEM Yazaki
Series: 050 Sealed
OEM P/N: 7283-7652
Mating Part: 7282-7652
Kit Contents: Housing, 5 socket contacts for 22-20 awg wire, 5 seals
Mfr: OEM Yazaki
Series: 050 Sealed
OEM P/N: 7283-7652
Mating Part: 7282-7652
General
- Sealing:Single Wire Sealed
- Number of Ways:5
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:1
- Pitch:3.0mm
- Numbered Cavities:No
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-30 - 80 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11182
050-SKT
050 Sealed Socket Contact
Mfr: Yazaki
Series: 050 Sealed
Mfr: Yazaki
Series: 050 Sealed
| Wire Size | Plating | P/N | |
|---|---|---|---|
| 050-SKT | .3-.5 mm2 (22-20 AWG) | Tin | 7116-4060-02 |
| - | Gold | 7116-4060-08 | |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Single Wire Sealed
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-30 - 80 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Terminal used in Toyota 82998-12650 repair wire
050-SL
050 Series Seal
Mfr: OEM Yazaki
Series: 050 Sealed
OEM P/N: 7157-3920-40
Mfr: OEM Yazaki
Series: 050 Sealed
OEM P/N: 7157-3920-40
For wire insulation dia. 1.2-1.8 mm (.047-.071 in)
General
- Sealing:Single Wire Sealed
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
Mechanical
- Seal Material:NBR
Environmental
- Temp Range[2]:-30 - 80 °C
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For detailed characteristics, see applicable product documents.
050U-10S
10-Way Kit
Kit Contents: Housing, 10 socket contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7283-7602
Mating Part: 7282-7602
Kit Contents: Housing, 10 socket contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7283-7602
Mating Part: 7282-7602
General
- Sealing:Unsealed
- Number of Ways:10
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:1
- Pitch:2.5mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11657
050U-14S
14-Way Kit
Kit Contents: Housing, 14 socket contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7283-7644
Mating Part: N/A, device only
Kit Contents: Housing, 14 socket contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7283-7644
Mating Part: N/A, device only
General
- Sealing:Unsealed
- Number of Ways:14
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:2
- Pitch:2.5mm
- Row Spacing:5.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:HPA
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11556
050U-22P-1
22-Way Kit
Kit Contents: Housing, 22x pin contacts for 22-20 AWG wire
Mfr: OEM Sumitomo
Series: TS 050 Unsealed
OEM P/N: 6098-0903
Part Name: 11503N5A22M-NA
Mating Part: 6098-0916
Kit Contents: Housing, 22x pin contacts for 22-20 AWG wire
Mfr: OEM Sumitomo
Series: TS 050 Unsealed
OEM P/N: 6098-0903
Part Name: 11503N5A22M-NA
Mating Part: 6098-0916
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11503
050U-2P
2-Way Kit
Kit Contents: Housing, 2 pin contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7282-7623
Mating Part: 050U-2S
Kit Contents: Housing, 2 pin contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7282-7623
Mating Part: 050U-2S
General
- Sealing:Unsealed
- Number of Ways:2
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:1
- Pitch:2.5mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11368
050U-2S
2-Way Kit
Kit Contents: Housing, 2 socket contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7283-7623
Mating Part: 050U-2P
Kit Contents: Housing, 2 socket contacts for 22-20 AWG wire
Mfr: OEM Yazaki
Series: 050 Unsealed
OEM P/N: 7283-7623
Mating Part: 050U-2P
General
- Sealing:Unsealed
- Number of Ways:2
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
- Number of Rows:1
- Pitch:2.5mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:3A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11369
050U-PIN
050 Unsealed Pin Contact
Mfr: Sumitomo, Yazaki
Series: TS 050 Unsealed, TS 050+090 Hybrid, 050 Unsealed
Mfr: Sumitomo, Yazaki
Series: TS 050 Unsealed, TS 050+090 Hybrid, 050 Unsealed
| Wire Size | Sumitomo | Yazaki | |
|---|---|---|---|
| 050U-PIN | .3-.5 mm2 (22-20 AWG) | 1500-0181 | 7114-1257-02 |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Unsealed
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
Electrical
- Current Rating[1]:3A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- KET ST740753-3
- Terminal used in Toyota 82998-12410 repair wire
050U-SKT
050 Unsealed Socket Contact
Mfr: Sumitomo, Yazaki
Series: TS 050 Unsealed, TS 050+090 Hybrid, 050 Unsealed
Mfr: Sumitomo, Yazaki
Series: TS 050 Unsealed, TS 050+090 Hybrid, 050 Unsealed
| Wire Size | Sumitomo | Yazaki | |
|---|---|---|---|
| 050U-SKT | .3-.5 mm2 (22-20 AWG) | 8100-0544 | 7116-1257-02 |
| Available stock: Aftermarket OEM | |||
General
- Sealing:Unsealed
- Contact Size:1.3mm (.050)
- Wire Size:0.30 - 0.50 mm2
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
Electrical
- Current Rating[1]:3A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- KET ST730751-3
- KUM MT405-01050
- Terminal used in Toyota 82998-12420 repair wire
050U/090IIU-14S
14-Way (8+6) Hybrid Kit
Kit Contents: Housing, 8x 050 socket contacts for 22-20awg wire, 6x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: 6098-1139
Part Name: 11591NYA14F-NA
Mating Part: 6098-1137
Kit Contents: Housing, 8x 050 socket contacts for 22-20awg wire, 6x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: 6098-1139
Part Name: 11591NYA14F-NA
Mating Part: 6098-1137
General
- Sealing:Unsealed
- Number of Ways:14
- Contact Size:Mixed
- Wire Size:0.22 - 2.00 mm2
- Number of Rows:2
- Pitch:Multiple
- Row Spacing:5.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11591
050U/090IIU-16S
16-Way (6+10) Hybrid Kit
Kit Contents: Housing, 6x 050 socket contacts for 22-20awg wire, 10x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: 6098-1063
Part Name: 11562NYA16F-NA
Mating Part: 6098-1061
Kit Contents: Housing, 6x 050 socket contacts for 22-20awg wire, 10x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: 6098-1063
Part Name: 11562NYA16F-NA
Mating Part: 6098-1061
General
- Sealing:Unsealed
- Number of Ways:16
- Contact Size:Mixed
- Wire Size:0.22 - 2.00 mm2
- Number of Rows:2
- Pitch:Multiple
- Row Spacing:5.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11562
050U/090IIU-20S
20-Way (16+4) Hybrid Kit
Kit Contents: Housing, 16x 050 socket contacts for 22-20awg wire, 4x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: Natural: 6098-0913 (In Stock)
Orange: 6098-0931
Blue: 6098-1159
Part Name: 11469NYA20F-NA
Mating Part: 6098-0909
Kit Contents: Housing, 16x 050 socket contacts for 22-20awg wire, 4x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: Natural: 6098-0913 (In Stock)
Orange: 6098-0931
Blue: 6098-1159
Part Name: 11469NYA20F-NA
Mating Part: 6098-0909
General
- Sealing:Unsealed
- Number of Ways:20
- Contact Size:Mixed
- Wire Size:0.22 - 2.00 mm2
- Number of Rows:2
- Pitch:Multiple
- Row Spacing:5.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11469 (Sumitomo), 90980-11715
050U/090IIU-38S
38-Way (16+22) Hybrid Kit
Kit Contents: Housing, 16x 050 socket contacts for 22-20awg wire, 22x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: Natural: 6098-0991 (In Stock)
Orange: 6098-1016
Part Name: 11555NYA38F
Kit Contents: Housing, 16x 050 socket contacts for 22-20awg wire, 22x 090 socket contacts
Mfr: OEM Sumitomo
Series: TS 050+090 Hybrid Unsealed
OEM P/N: Natural: 6098-0991 (In Stock)
Orange: 6098-1016
Part Name: 11555NYA38F
General
- Sealing:Unsealed
- Number of Ways:20
- Contact Size:Mixed
- Wire Size:0.22 - 2.00 mm2
- Number of Rows:4
- Pitch:Multiple
- Row Spacing:5.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Free hanging
- TPA:Yes
- CPA:Yes
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11555
090/250-9S
9-Way (7+2) Hybrid Kit
Kit Contents: Housing, 7x 090 socket terminals and seals, 2x 250 socket terminals and seals
Mfr: OEM Tokai Rika
Series: 2.3+6.3 (090+250) Hybrid Sealed Series
OEM P/N: 4F0958-000x
Mating Part: N/A, device only
Kit Contents: Housing, 7x 090 socket terminals and seals, 2x 250 socket terminals and seals
Mfr: OEM Tokai Rika
Series: 2.3+6.3 (090+250) Hybrid Sealed Series
OEM P/N: 4F0958-000x
Mating Part: N/A, device only
Informational listing only. This connector is obsolete with no replacement, but uses a terminal that is stocked and available to repin an existing connector.
General
- Sealing:Single Wire Sealed
- Number of Ways:9
- Contact Size:Mixed
- Wire Size:0.30 - 3.00 mm2
- Number of Rows:2
- Pitch:Multiple
- Row Spacing:Multiple
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:19A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
- Toyota 90980-10686
090II-12P
12-Way Kit
Kit Contents: Housing, 12 pin contacts, 12 seals
Mfr: OEM Tokai Rika
Series: 2.3II (090II) Sealed Series
OEM P/N: 4G1292-0000 (Black)
4G1298-0000 (Light Gray)
Mating Part: 090II-12S
Kit Contents: Housing, 12 pin contacts, 12 seals
Mfr: OEM Tokai Rika
Series: 2.3II (090II) Sealed Series
OEM P/N: 4G1292-0000 (Black)
4G1298-0000 (Light Gray)
Mating Part: 090II-12S
General
- Sealing:Single Wire Sealed
- Number of Ways:12
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:3
- Pitch:6.0mm
- Row Spacing:6.5mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:19A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- Sumitomo 6181-0132 (lt. grey), 6181-0564 (black)
- Toyota 90980-11086
- Yazaki 7282-7427
090II-12S
12-Way Kit
Kit Contents: Housing, 12 socket contacts, 12 seals
Mfr: OEM Tokai Rika
Series: 2.3II (090II) Sealed Series
OEM P/N: 4F1272-0003 (Black)
4F1278-0000 (Light gray)
Mating Part: 090II-12P
Kit Contents: Housing, 12 socket contacts, 12 seals
Mfr: OEM Tokai Rika
Series: 2.3II (090II) Sealed Series
OEM P/N: 4F1272-0003 (Black)
4F1278-0000 (Light gray)
Mating Part: 090II-12P
General
- Sealing:Single Wire Sealed
- Number of Ways:12
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:3
- Pitch:6.0mm
- Row Spacing:6.5mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:19A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- Sumitomo 6189-0221 (gray)
- Toyota 90980-11087
- Yazaki 7283-7427
090II-1S-1
1-Way Kit
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1015-10
Mating Part: N/A
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1015-10
Mating Part: N/A
General
- Sealing:Single Wire Sealed
- Number of Ways:1
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Numbered Cavities:No
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11166 (grey)
090II-1S-2
1-Way Kit
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1019-40
Mating Part: N/A
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1019-40
Mating Part: N/A
General
- Sealing:Single Wire Sealed
- Number of Ways:1
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Numbered Cavities:No
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11243 (grey)
090II-1S-3
1-Way Kit
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1114-40
Mating Part: N/A
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1114-40
Mating Part: N/A
General
- Sealing:Single Wire Sealed
- Number of Ways:1
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Numbered Cavities:No
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Free hanging
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11363
090II-1S-6
1-Way Kit
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Tokai Rika
Series: 2.3II (090II) Sealed Series
OEM P/N: 4F0188-0005 Light gray (IN STOCK)
4F0182-000x Black
Mating Part: N/A, device only
Kit Contents: Housing, 1 socket contact, 1 seal
Mfr: OEM Tokai Rika
Series: 2.3II (090II) Sealed Series
OEM P/N: 4F0188-0005 Light gray (IN STOCK)
4F0182-000x Black
Mating Part: N/A, device only
General
- Sealing:Single Wire Sealed
- Number of Ways:1
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Numbered Cavities:No
Mechanical
- Contact Type:Socket, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Seal Material:Silicone Rubber
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:19A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
- Sumitomo 1300-3629
- Toyota 90980-11007
- Yazaki 7283-1013-40
090II-2P-1
2-Way Kit
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-7023-10
Mating Part: 090II-2S-1
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-7023-10
Mating Part: 090II-2S-1
General
- Sealing:Single Wire Sealed
- Number of Ways:2
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Pitch:6.4mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-10959
090II-2P-12
2-Way Kit
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-8129-40
Mating Part: 090II-2S-12
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-8129-40
Mating Part: 090II-2S-12
General
- Sealing:Single Wire Sealed
- Number of Ways:2
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Pitch:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11254
090II-2P-4
2-Way Kit
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-7020-10
Mating Part: 090II-2S-4
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-7020-10
Mating Part: 090II-2S-4
General
- Sealing:Single Wire Sealed
- Number of Ways:2
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Pitch:6.4mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-10898
090II-2P-5
2-Way Kit
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-8120-40
Mating Part: 090II-2S-5
Kit Contents: Housing, 2 pin contacts, 2 seals
Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-8120-40
Mating Part: 090II-2S-5
General
- Sealing:Single Wire Sealed
- Number of Ways:2
- Contact Size:2.3mm (.090)
- Wire Size:0.30 - 2.00 mm2
- Number of Rows:1
- Pitch:6.0mm
- Numbered Cavities:Yes, Numbered
Mechanical
- Contact Type:Pin, flat
- Termination:Open barrel crimp
- Lance Type:Housing Lance
- Housing Material:PBT
- Mounting Style:Clip Slot
- TPA:Yes
- CPA:No
Electrical
- Current Rating[1]:10A
Environmental
- Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
- Toyota 90980-11168
© 2009-2025 Corsa Technic, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
