3-Way

65 Items.  Showing Items 1 thru 50.
 1  2   Next »   Show All
3-Way Kit
250.ARM-3P
3-Way Kit
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7122-2137-30 (PA66), 7122-2237-30 (PP)
Natural | 6111-2556 (PA66), 6070-3381 (PP) | 7122-2137 (PA66), 7122-2237 (PP)
250.ARM-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: 250 Armlock series, CN(A) Tang Type Terminal
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7122-2137-30 (PA66), 7122-2237-30 (PP)
Natural | 6111-2556 (PA66), 6070-3381 (PP) | 7122-2137 (PA66), 7122-2237 (PP)
Mating Part: 250.ARM-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Hero B-38R (male half)
QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100-249$0.90
250-499$0.84
500+$0.77
Quantity:  Kit

3-Way Kit
250.ARM-3S
3-Way Kit
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7123-2137-30 (PA66), 7123-2237-30 (PP)
Natural | 6111-2557 (PA66), 6070-3391 (PP) | 7123-2137 (PA66), 7123-2237 (PP)
250.ARM-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: 250 Armlock series, CN(A) Tang Type Terminal
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7123-2137-30 (PA66), 7123-2237-30 (PP)
Natural | 6111-2557 (PA66), 6070-3391 (PP) | 7123-2137 (PA66), 7123-2237 (PP)
Mating Part: 250.ARM-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Hero B-38R (female half)
QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100-249$0.90
250-499$0.84
500+$0.77
Quantity:  Kit

3-Way Kit
250.HL-3P
3-Way Kit
250.HL-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: AMP/TE, Sumitomo, Yazaki
Series: 250 Housing Lance, 250 Armlock-Housing Lance, CN(A) Plastic Lock-Arm
Mating Part: 250.HL-3S

AMP/TESumitomoYazaki
172131-16070-36217122-2830
Available stock: Aftermarket OEM

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100+$0.90
Quantity:  Kit

3-Way Kit
250.HL-3S
3-Way Kit
250.HL-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: AMP/TE, Sumitomo, Yazaki
Series: 250 Housing Lance, 250 Armlock-Housing Lance, CN(A) Plastic Lock-Arm
Mating Part: 250.HL-3P

AMP/TESumitomoYazaki
172132-16070-36117123-2830
Available stock: Aftermarket OEM

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100+$0.90
Quantity:  Kit

3-Way Kit
250.LOC-3P
3-Way Kit
250.LOC-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo
Series: 250 Lock series
Mating Part: 250.LOC-3S
P/N:
Natural, 6120-2033 (PP), 6010-3041 (PA66)
Black, ()

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KTM 000700000DD
QtyPrice
1-5$1.45
6-19$1.35
20-49$1.23
50-99$1.16
100+$1.01
Quantity:  Kit

3-Way Kit
250.LOC-3S
3-Way Kit
250.LOC-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo
Series: 250 Lock series
Mating Part: 250.LOC-3P
P/N:
Natural, 6110-4533 (PP)(6020-3261 w/flange)
Black, ()

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KTM 000700000DC
QtyPrice
1-5$1.45
6-19$1.35
20-49$1.23
50-99$1.16
100+$1.01
Quantity:  Kit

3-Way Kit
250.LT-3P
3-Way Kit
OEM P/N: 6120-0533
250.LT-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: Sumitomo 250 LT Type
OEM P/N: 6120-0533
Mating Part: 250.LT-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PP
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-20 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KUM PH021-03010
  • Yazaki 7123-2030
QtyPrice
1-5$2.80
6-19$2.60
20-49$2.38
50-99$2.24
100+$1.96
Quantity:  Kit

3-Way Kit
250.LT-3S
3-Way Kit
OEM P/N: 6110-2533 (alt p/n w/flange 6110-0333)
250.LT-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: Sumitomo 250 LT Type
OEM P/N: 6110-2533 (alt p/n w/flange 6110-0333)
Mating Part: 250.LT-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PP
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-20 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.80
6-19$2.60
20-49$2.38
50-99$2.24
100+$1.96
Quantity:  Kit

4.0mm Triple Bullet Receptacle kit
BC40-3S
4.0mm Triple Bullet Receptacle kit
BC40-3S  4.0mm Triple Bullet Receptacle kit
Note: This is not classified as a sealed connector. The sleeve function is to provide electrical insulation only.

Kit Contents: 1 terminal and 1 insulator

Mating Part: Accepts 3x BC40-1P-A

spacer

QtyPrice
1-49$0.59
50-99$0.53
100-249$0.47
250-499$0.41
500-999$0.35
1000+$0.29
Quantity:  Kit

3-Way Kit
HC050-3P
3-Way Kit
OEM P/N: Natural: 6098-3752
Blue: 6098-3858
Orange: 6098-3859
Gray: 6098-4434
Black: 6098-4435
HC050-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: OEM Sumitomo
Series: HC 050 Unsealed Series
OEM P/N: Natural: 6098-3752
Blue: 6098-3858
Orange: 6098-3859
Gray: 6098-4434
Black: 6098-4435
Part Name: HC050-3M-x
Mating Part: HC050-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:1.3mm (.050)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:2
  • Pitch:Multiple
  • Row Spacing:Multiple
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:9A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$3.28
6-19$3.12
20-49$2.95
50-99$2.79
100+$2.62
Quantity:  Kit

3-Way Kit
HC050-3S
3-Way Kit
OEM P/N: Natural: 6098-3751
Blue: 6098-3854
Orange: 6098-3855
Gray: 6098-4438
Black: 6098-4439
HC050-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Sumitomo
Series: HC 050 Unsealed Series
OEM P/N: Natural: 6098-3751
Blue: 6098-3854
Orange: 6098-3855
Gray: 6098-4438
Black: 6098-4439
Part Name: HC050-3F-x
Mating Part: HC050-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:1.3mm (.050)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:2
  • Pitch:Multiple
  • Row Spacing:Multiple
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:9A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.99
6-19$2.84
20-49$2.69
50-99$2.54
100+$2.39
Quantity:  Kit

3-Way Kit
HD090-3P
3-Way Kit
OEM P/N: 6098-0242
HD090-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: OEM Sumitomo
Series: HD 090 Unsealed Series
OEM P/N: 6098-0242
Mating Part: HD090-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.12
6-19$1.97
20-49$1.80
50-99$1.70
100+$1.48
Quantity:  Kit

3-Way Kit
HD090-3S
3-Way Kit
OEM P/N: 6098-0241
HD090-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Sumitomo
Series: HD 090 Unsealed Series
OEM P/N: 6098-0241
Mating Part: HD090-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.04
6-19$1.90
20-49$1.73
50-99$1.63
100+$1.43
Quantity:  Kit

3-Way Kit
HM-3P
3-Way Kit
OEM P/N: 6187-3801
HM-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: Aftermarket Sumitomo
Series: HM Sealed Series
OEM P/N: 6187-3801
Mating Part: HM-3S
Bottom of connector features a bracket mount

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Speed sensor on GSXR (harness side, black)
  • Speed sensor on Hayabusa 99'-07' (harness side, black)
  • Ducati Monster 09'-14' 696, 796, 1100S Brake light (light assy side, natural)
spacer
  • Hero FRSH-108
  • Honda 07VPZ-002060A
  • KTM 000700000EY
  • Suzuki 09900-28710-013 (Natural)
QtyPrice
1-5$3.08
6-19$2.86
20-49$2.62
50-99$2.46
100-499$2.16
500-999$1.85
1000+$1.69
Quantity:  Kit

3-Way Kit
HM-3S
3-Way Kit
OEM P/N: 6180-3451
HM-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: Aftermarket Sumitomo
Series: HM Sealed Series
OEM P/N: 6180-3451
Part Name: HM090WP03F
Mating Part: HM-3P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Speed sensor on GSXR (sensor side, black)
  • Speed sensor on Hayabusa 99'-07' (sensor side, black)
  • Ducati Monster 09'-14' 696, 796, 1100S Brake light (harness side, natural)
spacer
  • Hero FRSH-109
  • Suzuki 09900-28710-014 (Natural)
QtyPrice
1-5$1.98
6-19$1.84
20-49$1.68
50-99$1.58
100+$1.39
Quantity:  Kit

3-Way Kit
HMU-3P
3-Way Kit
OEM P/N: 6090-1131
HMU-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: OEM Sumitomo
Series: HM Unsealed Series
OEM P/N: 6090-1131
Mating Part: HMU-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$1.58
6-19$1.50
20-49$1.42
50-99$1.34
100+$1.26
Quantity:  Kit

3-Way Kit
HMU-3S
3-Way Kit
OEM P/N: 6090-1136
HMU-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Sumitomo
Series: HM Unsealed Series
OEM P/N: 6090-1136
Mating Part: HMU-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$1.39
6-19$1.32
20-49$1.25
50-99$1.18
100+$1.11
Quantity:  Kit

3-Way Kit
HS-3P
3-Way Kit
OEM P/N: 7282-2147-30
HS-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: OEM Yazaki
Series: HS 025 Series
OEM P/N: 7282-2147-30
Mating Part: HS-3S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:0.64mm (.025)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:1
  • Pitch:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.34
6-19$3.17
20-49$3.01
50-99$2.84
100+$2.67
Quantity:  Kit

3-Way Kit
HS-3S
3-Way Kit
OEM P/N: 7283-2147-30
HS-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Yazaki
Series: HS 025 Series
OEM P/N: 7283-2147-30
Part Name: HS03FB
Mating Part: HS-3P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:0.64mm (.025)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:1
  • Pitch:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Nissan/Bosch J-48817-185 pigtail connector
  • Nissan service part 24008-9DM0B connector
This item is backordered.
QtyPrice
1-5$3.96
6-19$3.76
20-49$3.56
50-99$3.37
100+$3.17
Quantity:  Kit

3-Way Kit
HU-3S
3-Way Kit
OEM P/N: PK605-03027
HU-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: Aftermarket Furukawa
Series: HU Series
OEM P/N: PK605-03027
Part Name: HU03F-B SA'Y
Mating Part: PK601-03027

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:0.64mm (.025)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:1
  • Pitch:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KTM 000700000DX
QtyPrice
1-5$3.76
6-19$3.50
20-49$3.20
50-99$3.01
100+$2.63
Quantity:  Kit

3-Way Kit
HVG-3P-1
3-Way Kit
OEM P/N: 6188-4775
HVG-3P-1  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: OEM Sumitomo
Series: HV/HVG Sealed Series
OEM P/N: 6188-4775
Mating Part: HVG-3S-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.1mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Honda 070PZ-Z5TA200
QtyPrice
1-5$3.77
6-19$3.58
20-49$3.39
50-99$3.20
100-249$3.02
250+$2.83
Quantity:  Kit

3-Way Kit
HVG-3S-1
3-Way Kit
OEM P/N: 6189-7037
HVG-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, TPA lock

Mfr: OEM Sumitomo
Series: HV/HVG Sealed Series
OEM P/N: 6189-7037
Mating Part: HVG-3P-1
Cross-compatible with 6189-6907 (HV type, without finger ribs)

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.1mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$3.57
6-19$3.39
20-49$3.21
50-99$3.03
100-249$2.86
250+$2.68
Quantity:  Kit

3-Way Kit
HW-3P-1
3-Way Kit
OEM P/N: 6181-0071
HW-3P-1  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals, TPA lock

Mfr: OEM Sumitomo
Series: HW Sealed Series
OEM P/N: 6181-0071
Mating Part: HW-3S-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.28
6-19$3.12
20-49$2.95
50-99$2.79
100+$2.62
Quantity:  Kit

3-Way Kit
HW-3P-2
3-Way Kit
OEM P/N: 6181-0072
HW-3P-2  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals, TPA lock

Mfr: OEM Sumitomo
Series: HW Sealed Series
OEM P/N: 6181-0072
Mating Part: HW-3S-2

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:4.8mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.28
6-19$3.12
20-49$2.95
50-99$2.79
100+$2.62
Quantity:  Kit

3-Way Kit
HW-3S-1
3-Way Kit
OEM P/N: 6189-0130
HW-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, TPA lock

Mfr: Aftermarket Sumitomo
Series: HW Sealed Series
OEM P/N: 6189-0130
Mating Part: HW-3P-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • CBR front wheelspeed
QtyPrice
1-5$2.79
6-19$2.59
20-49$2.37
50-99$2.23
100+$1.95
Quantity:  Kit

3-Way Kit
HW-3S-2
3-Way Kit
OEM P/N: 6189-0131
HW-3S-2  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, TPA lock

Mfr: OEM Sumitomo
Series: HW Sealed Series
OEM P/N: 6189-0131
Mating Part: HW-3P-2

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:4.8mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:NBR
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.79
6-19$3.60
20-49$3.41
50-99$3.22
100+$3.03
Quantity:  Kit

3-Way Kit
HW-3S-3
3-Way Kit
OEM P/N: 6189-0154
HW-3S-3  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, TPA lock

Mfr: Aftermarket Sumitomo
Series: HW Sealed Series
OEM P/N: 6189-0154
Part Name: HW09T/S3FAY-DGR
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:5.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • VFR1000 TPS
  • Honda B-series TPS
spacer
  • Honda 986CC-0000300
QtyPrice
1-5$4.07
6-19$3.79
20-49$3.46
50-99$3.26
100+$2.85
Quantity:  Kit

3-Way Kit
HX040-3S-1
3-Way Kit
OEM P/N: Black: 6189-0887
Dark Blue: 6189-0970
HX040-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, front lock

Mfr: OEM Sumitomo
Series: HX 040 Sealed Series
OEM P/N: Black: 6189-0887
Dark Blue: 6189-0970
Part Name: HX4-DC3FAY2-B, HX4DCV3FAY-DL
Mating Part: HX040-3P-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.1mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • CBR 1000RR TPS, MAP (blue)
  • GL1800 tail light (black)
  • Acura, Honda K series MAP sensor
spacer
  • KTM 000700000FT
QtyPrice
1-5$3.49
6-19$3.32
20-49$3.14
50-99$2.97
100-249$2.79
250-499$2.62
500-999$2.44
1000+$2.27
Quantity:  Kit

3-Way Kit
HX040-3S-2
3-Way Kit
OEM P/N: 6189-0968
HX040-3S-2  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, front lock

Mfr: OEM Sumitomo
Series: HX 040 Sealed Series
OEM P/N: 6189-0968
Part Name: HX4DCDV3FAY-DGR
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.1mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$3.49
6-19$3.32
20-49$3.14
50-99$2.97
100+$2.79
Quantity:  Kit

3-Way Kit
HX090-3P-1
3-Way Kit
HX090-3P-1  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: Aftermarket, Sumitomo does not make an actual part.
Series: HX 090 Sealed Series
Mating Part: HX090-3S-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.64
6-19$2.46
20-49$2.24
50-99$2.11
100+$1.85
Quantity:  Kit

3-Way Kit
JPT-3P
3-Way Kit
OEM P/N: 1-962581-2, ss: 1-962581-1
JPT-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: OEM Tyco/AMP
Series: Junior Power Timer Series
OEM P/N: 1-962581-2, ss: 1-962581-1
Part Name: FLACHST-GH2,8 EDS3P
Mating Part: JPT-3S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.20 - 2.50 mm2
  • Number of Rows:1
  • Pitch:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66+GF
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
  • Voltage Rating:24V DC
Environmental
  • Temp Range[2]:-40 - 120 °C
  • Protection Rating:IPX4A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • BMW 12.52.1.732.564 (12521732564), 1732564-01
QtyPrice
1-5$3.63
6-19$3.45
20-49$3.27
50-99$3.09
100+$2.90
Quantity:  Kit

3-Way Kit
JWPF-3P
3-Way Kit
OEM P/N: 03T-JWPF-VSLE-S
JWPF-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts for 26-22 AWG wire

Mfr: OEM JST
Series: JWPF Series
OEM P/N: 03T-JWPF-VSLE-S
Mating Part: JWPF-3S

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:0.64mm (.025)
  • Wire Size:0.13 - 0.35 mm2
  • Number of Rows:1
  • Pitch:2.0mm
  • Row Spacing:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-55 - 85 °C
  • Protection Rating:IPX7
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Various Ducati and KTM
spacer
  • KTM 000700000CZ
QtyPrice
1-5$1.82
6-19$1.69
20-49$1.55
50-99$1.46
100-249$1.36
250-499$1.33
500+$1.27
Quantity:  Kit

3-Way Kit
JWPF-3S
3-Way Kit
OEM P/N: 03R-JWPF-VSLE-S
JWPF-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts for 26-22 AWG wire

Mfr: OEM JST
Series: JWPF Series
OEM P/N: 03R-JWPF-VSLE-S
Mating Part: JWPF-3P

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:0.64mm (.025)
  • Wire Size:0.13 - 0.35 mm2
  • Number of Rows:1
  • Pitch:2.0mm
  • Row Spacing:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-55 - 85 °C
  • Protection Rating:IPX7
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Various Ducati and KTM
spacer
  • KTM 000700000CY
QtyPrice
1-5$1.12
6-19$1.04
20-49$0.95
50-99$0.90
100-249$0.84
250-499$0.78
500+$0.73
Quantity:  Kit

3-Way Kit, Code 1
KOM1-3S-1
3-Way Kit, Code 1
OEM P/N: 1 928 403 110
Special variant (clean exit): 1 928 402 868 available on special order
KOM1-3S-1  3-Way Kit, Code 1
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Bosch
Series: Kompakt 1
OEM P/N: 1 928 403 110
Special variant (clean exit): 1 928 402 868 available on special order
Code: 1
Mating Part: 1 928 404 227

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.35 - 2.50 mm2
  • Number of Rows:1
  • Pitch:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66+GF30
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
  • Voltage Rating:40V
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IPX 4K,6K,9K, 7
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.16
6-19$3.87
20-49$3.54
50-99$3.33
100+$2.91
Quantity:  Kit

3-Way Receptacle Kit
LPSCT-3S
3-Way Receptacle Kit
LPSCT-3S  3-Way Receptacle Kit
Kit Contents: Housing, 3x socket contacts for 20-16 AWG wire

Mfr: Aftermarket Sumitomo
Series: LPSCT Series
Part Name: LPSCT-3F

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:1.9mm (.075)
  • Wire Size:0.50 - 1.25 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:12A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Certain Honda tail lights
QtyPrice
1-5$2.04
6-19$1.90
20-49$1.73
50-99$1.63
100+$1.43
Quantity:  Kit

3-Way Kit
MP150.2-3S
3-Way Kit
OEM P/N: 12162182
MP150.2-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Delphi
Series: Metri-Pack 150.2 Pull to Seat Series
OEM P/N: 12162182
Mating Part: N/A

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 1.00 mm2
  • Number of Rows:1
  • Pitch:3.5mm
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:14A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ducati TPS, on ST2, 748, 996, 998, Monster (Magneti Marelli PF1C, PF3C or CTS 175 sensor)
  • MV Agusta TPS
  • Moto Guzzi TPS
spacer
  • Harley Davidson 72280-95
  • Ford 3U2Z-14S411-KHA, WPT-406 (Tin plated terminals) pigtail connector
QtyPrice
1-5$4.34
6-19$4.12
20-49$3.91
50-99$3.69
100+$3.47
Quantity:  Kit

3-Way Kit
MP150.2-3S-2B
3-Way Kit
OEM P/N: 12162280
MP150.2-3S-2B  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Delphi
Series: Metri-Pack 150.2 Pull to Seat Series
OEM P/N: 12162280
Mating Part: N/A

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 1.00 mm2
  • Number of Rows:1
  • Pitch:3.5mm
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:14A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.71
6-19$4.47
20-49$4.24
50-99$4.00
100+$3.77
Quantity:  Kit

3-Way Kit
MP150P-3S
3-Way Kit
OEM P/N: 12065287
MP150P-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Delphi
Series: Metri-Pack 150 Pull to Seat Series
OEM P/N: 12065287
Mating Part: N/A, device only

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 1.00 mm2
  • Number of Rows:2
  • Pitch:3.5mm
  • Row Spacing:3.4mm
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:14A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Oil pressure sensor on some newer Ducati models
QtyPrice
1-5$3.75
6-19$3.56
20-49$3.38
50-99$3.19
100+$3.00
Quantity:  Kit

3-Way Kit
MT-3P-2
3-Way Kit
OEM P/N: 6187-3231
MT-3P-2  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: Aftermarket Sumitomo
Series: MT Sealed Series
OEM P/N: 6187-3231
Mating Part: MT-3S-2

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:5.2mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • TRE connector on Kawasaki motorcycles
  • Ducati side stand switch on 899, 1199 (harness side)
  • Suzuki
  • TRE connector on Suzuki GSXR's & TL's. For SV's see HM-4P
  • GSXR-600 camshaft sensor on 06-17 (sensor side, black)
  • GSXR-750 camshaft sensor on 06-17 (sensor side, black)
  • GSXR-1000 camshaft sensor on 07-17 (sensor side, black)
  • GSXR-1000 fuel pump/sender on 03-16 (fuel pump side, white)
  • Hayabusa camshaft sensor on 08-17 (sensor side, black)
  • GSXR gear position, neutral sensor (harness side)
  • GSXR 1000 2nd throttle position sensor on 06'> (sensor side)
  • 07> GSXR Crank sensor (harness side)
  • Yamaha
  • YZF-R6 crank sensor 06-09', neutral sensor
  • YZF-R6 TPS 99-02' (sensor side, white)
spacer
  • Hero FRS-108N
  • KTM 000700000AR
  • Suzuki 09900-28710-004 (White)
QtyPrice
1-5$2.89
6-19$2.75
20-49$2.60
50-99$2.46
100-249$2.31
250-499$2.17
500-999$2.02
1000-2499$1.88
2500+$1.73
Quantity:  Kit

3-Way Kit
MT-3S-1
3-Way Kit
OEM P/N: 6180-3261
MT-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6180-3261
Mating Part: MT-3P-1-CLIP

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.74
6-19$2.60
20-49$2.47
50-99$2.33
100+$2.19
Quantity:  Kit

3-Way Kit
MT-3S-2
3-Way Kit
OEM P/N: 6180-3241
MT-3S-2  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: Aftermarket Sumitomo
Series: MT Sealed Series
OEM P/N: 6180-3241
Mating Part: MT-3P-2

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:5.2mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ducati side stand switch on 899, 1199 (sensor side)
  • TRE connector on Kawasaki motorcycles
  • Suzuki
  • TRE connector on Suzuki GSXR's & TL's. For SV's see HM-4P
  • GSXR-600 camshaft sensor on 06-17 (harness side, black)
  • GSXR-750 camshaft sensor on 06-17 (harness side, black)
  • GSXR-1000 camshaft sensor on 07-17 (harness side, black)
  • GSXR-1000 fuel pump/sender on 03-16 (harness side, white)
  • Hayabusa camshaft sensor on 08-17 (harness side, black)
  • GSXR gear position, neutral sensor (harness side)
  • GSXR 1000 2nd throttle position sensor on 06'> (sensor side)
  • Yamaha
  • YZF-R6 TPS 99-02' (sensor side, white)
  • YZF-R6 crank sensor 06-09', neutral sensor
spacer
  • Hero FRS-109N
  • KTM 000700000AM
  • Suzuki 09900-28710-005 (White)
QtyPrice
1-5$2.03
6-19$1.93
20-49$1.83
50-99$1.73
100-249$1.62
250-499$1.52
500-999$1.42
1000-2499$1.32
2500+$1.22
Quantity:  Kit

3-Way Kit
MT-3S-3
3-Way Kit
OEM P/N: 6189-0027
MT-3S-3  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6189-0027
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Honda 070MZ-002A700 (Grey)
QtyPrice
1-5$3.28
6-19$3.05
20-49$2.79
50-99$2.62
100+$2.30
Quantity:  Kit

3-Way Kit
MT-3S-4
3-Way Kit
OEM P/N: 6189-0028
MT-3S-4  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6189-0028
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.78
6-19$3.52
20-49$3.21
50-99$3.02
100+$2.65
Quantity:  Kit

3-Way Kit
MTU.SL-3P
3-Way Kit
OEM P/N: 6242-1031, 7122-1430
MTU.SL-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: MT Unsealed Semi-Locking, 090 Unsealed
OEM P/N: 6242-1031, 7122-1430
Mating Part: MTU.SL-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.96
6-19$1.82
20-49$1.67
50-99$1.57
100+$1.37
Quantity:  Kit

3-Way Kit
MTU.SL-3S
3-Way Kit
OEM P/N: 6242-5031, 7123-1430
MTU.SL-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: MT Unsealed Semi-Locking, 090 Unsealed
OEM P/N: 6242-5031, 7123-1430
Mating Part: MTU.SL-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.96
6-19$1.82
20-49$1.67
50-99$1.57
100+$1.37
Quantity:  Kit

3-Way Kit
MTW-3P
3-Way Kit
OEM P/N: 6030-3991
MTW-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo
Series: MTW Series
OEM P/N: 6030-3991
Mating Part: MTW-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • CBR600 F4i speed sensor (harness side, black)
spacer
  • Hero B-98 (male half)
  • KTM 000700000BE (Natural)
QtyPrice
1-5$1.03
6-19$0.98
20-49$0.93
50-99$0.88
100-499$0.82
500-999$0.77
1000-1999$0.72
2000+$0.67
Quantity:  Kit

3-Way Kit
MTW-3S
3-Way Kit
OEM P/N: 6040-3111
MTW-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo
Series: MTW Series
OEM P/N: 6040-3111
Mating Part: MTW-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • CBR600 F4i speed sensor (sensor side, black)
  • Yamaha XT225 turn signal relay on 92-06 (harness side)
  • Mating half to turn signal relays: 4BE-83350-00-00, 4VR-83350-00-00 (Omron G8A-101-03)
spacer
  • Hero B-98 (female half)
  • KTM 000700000AG (Natural)
QtyPrice
1-5$1.03
6-19$0.98
20-49$0.93
50-99$0.88
100-499$0.82
500-999$0.77
1000-1999$0.67
2000+$0.62
Quantity:  Kit

3-Way Kit
N38-3P
3-Way Kit
OEM P/N: N3810-9103 Black
N3810-9903 Grey
N38-3P  3-Way Kit
Kit Contents: Housing, 3x pin contacts

Mfr: OEM NT
Series: N38 Series
OEM P/N: N3810-9103 Black
N3810-9903 Grey
Mating Part: N38-3S
For .3-.5 mm2 (22-20 AWG) wire, with 1.6-2.0mm (.063-.079") insulation dia.

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 0.50 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:6A
  • Voltage Rating:12V DC
Environmental
  • Temp Range[2]:-25 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.61
6-19$2.48
20-49$2.35
50-99$2.22
100+$2.09
Quantity:  Kit

3-Way Kit
N38-3S
3-Way Kit
OEM P/N: N3820-9103 Black
N3820-9903 Grey
N38-3S  3-Way Kit
Kit Contents: Housing, 3x socket contacts

Mfr: OEM NT
Series: N38 Series
OEM P/N: N3820-9103 Black
N3820-9903 Grey
Mating Part: N38-3P
For .3-.5 mm2 (22-20 AWG) wire, with 1.4-1.8mm (.055-.071") insulation dia.

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 0.50 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:6A
  • Voltage Rating:12V DC
Environmental
  • Temp Range[2]:-25 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.45
6-19$2.33
20-49$2.21
50-99$2.08
100+$1.96
Quantity:  Kit

3-Way Kit
QLW-3S-1
3-Way Kit
OEM P/N: QLW-A-B3F-B (alt p/n: Q011789, 13412-3203-2, FT0056)
QLW-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Furukawa
Series: QLW Series
OEM P/N: QLW-A-B3F-B (alt p/n: Q011789, 13412-3203-2, FT0056)
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:2.00 - 8.00 mm2
  • Number of Rows:1
  • Pitch:10.45mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:34A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Various regulator, rectifier
QtyPrice
1-5$7.95
6-19$7.55
20-49$7.16
50-99$6.76
100-249$6.36
250-499$5.96
500-999$5.57
1000+$5.17
Quantity:  Kit

65 Items.  Showing Items 1 thru 50.
 1  2   Next »   Show All

Facebook link spacer Instagram link spacer LinkedIn link spacer Twitter link spacer Twitter link
Privacy Notice | Terms and Conditions | Site Map
© 2009-2024 Corsa Technic, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
R6A1
R7A4
R7A3
R7A2
