Home ▹ Connectors ▹ By Application/Use ▹ Motorcycle/Sport-Bike ▹ 6-Way

6-Way

6-Way Kit
090II-6S-1
6-Way Kit
OEM P/N: 7283-1968-30
090II-6S-1  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1968-30
Mating Part: 090II-6P-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KTM 000700000GH
  • Nissan/Bosch J-48817-1125 pigtail connector
  • Nissan service part 24008-9DK4A connector
  • Toyota 90980-11858
QtyPrice
1-5$6.40
6-19$6.08
20-49$5.76
50-99$5.44
100-249$5.12
250+$4.80
Quantity:  Kit

6-Way Kit
250.ARM-6P-1
6-Way Kit
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7122-2162-30 (PA66), 7122-2262-30 (PP)
Natural | 6111-2007 (PA66), 6070-6381 (PP) | 7122-2162 (PA66), 7122-2262 (PP)
250.ARM-6P-1  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: 250 Armlock series, CN(A) Tang Type Terminal
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7122-2162-30 (PA66), 7122-2262-30 (PP)
Natural | 6111-2007 (PA66), 6070-6381 (PP) | 7122-2162 (PA66), 7122-2262 (PP)
Mating Part: 250.ARM-6S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:9.0mm
  • Row Spacing:5.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • FZR Ignitor (black)
spacer
  • Hero B-13R (male half)
QtyPrice
1-5$2.21
6-19$2.10
20-49$1.99
50-99$1.88
100-249$1.77
250-499$1.66
500+$1.55
Quantity:  Kit

6-Way Kit
250.ARM-6S-1
6-Way Kit
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7123-2165-30 (PA66), 7123-2262-30 (PP)
Natural | 6111-2008 (PA66), 6070-6391 (PP) | 7123-2165 (PA66), 7123-2262 (PP)
250.ARM-6S-1  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: 250 Armlock series, CN(A) Tang Type Terminal
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7123-2165-30 (PA66), 7123-2262-30 (PP)
Natural | 6111-2008 (PA66), 6070-6391 (PP) | 7123-2165 (PA66), 7123-2262 (PP)
Mating Part: 250.ARM-6P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:9.0mm
  • Row Spacing:5.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • FZR Ignitor (harness side)
spacer
  • Hero B-13R (female half)
  • Honda 070PZ-002A800
QtyPrice
1-5$2.21
6-19$2.10
20-49$1.99
50-99$1.88
100-249$1.77
250-499$1.66
500+$1.55
Quantity:  Kit

6-Way Kit
250.LOC-6P
6-Way Kit
250.LOC-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: Aftermarket Sumitomo
Series: 250 Lock series
Mating Part: 250.LOC-6S
P/N:
Natural, 6120-2063 (PP)
Black, ()

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:9.0mm
  • Row Spacing:5.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.40
6-19$2.23
20-49$2.04
50-99$1.92
100+$1.68
Quantity:  Kit

6-Way Kit
250.LOC-6S
6-Way Kit
250.LOC-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo
Series: 250 Lock series
Mating Part: 250.LOC-6P
P/N:
Natural, 6110-4563 (PP)
Black, ()

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:9.0mm
  • Row Spacing:5.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Panel Mount
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.40
6-19$2.23
20-49$2.04
50-99$1.92
100-499$1.80
500-999$1.56
1000-2499$1.44
2500-4999$1.20
5000+$0.96
Quantity:  Kit

6-Way ECU PCB Header
FSW-6P-ECU
6-Way ECU PCB Header
OEM P/N: FP-C-SW6M-B
FSW-6P-ECU  6-Way ECU PCB Header
Kit Contents: PCB Header

Mfr: OEM Furukawa
Series: FSW Series
OEM P/N: FP-C-SW6M-B
Part Name: FT0363
Mating Part: FSW-6S
Straight pins out back side

spacer
Electrical
  • Current Rating[1]:19A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$5.83
6-19$5.54
20-49$5.25
50-99$4.96
100+$4.66
Quantity:  Ea

6-Way Kit
HD090-6P
6-Way Kit
OEM P/N: 6098-0246
HD090-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Sumitomo
Series: HD 090 Unsealed Series
OEM P/N: 6098-0246
Mating Part: HD090-6S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.89
6-19$2.69
20-49$2.46
50-99$2.31
100+$2.02
Quantity:  Kit

6-Way Kit
HD090-6S
6-Way Kit
OEM P/N: 6098-0245
HD090-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: OEM Sumitomo
Series: HD 090 Unsealed Series
OEM P/N: 6098-0245
Mating Part: HD090-6P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.17
6-19$2.02
20-49$1.84
50-99$1.74
100+$1.52
Quantity:  Kit

6-Way Kit
HM-6P
6-Way Kit
OEM P/N: 6187-6801
HM-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals

Mfr: Aftermarket Sumitomo
Series: HM Sealed Series
OEM P/N: 6187-6801
Mating Part: HM-6S
Similar to MT-6P-2, but bottom of connector features a bracket mount

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Ducati ignition switch on 1199 (harness side)
  • Suzuki ignition switch on GSXR to 05' (harness side, green or black depending on year)
spacer
  • Hero FRSH-112
  • Honda 07VPZ-002050A (natural), 070PZ-0020100 (grey)
0x - Black - OUT OF STOCK - in stock.
QtyPrice
1-5$3.80
6-19$3.53
20-49$3.23
50-99$3.04
100-249$2.85
250-499$2.66
500-999$2.28
1000-2499$1.90
2500+$1.52
Quantity:  Kit

6-Way Kit
HM-6S
6-Way Kit
OEM P/N: 6180-6181
HM-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: Aftermarket Sumitomo
Series: HM Sealed Series
OEM P/N: 6180-6181
Mating Part: MT-6P-2 and HM-6P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Ducati DTC on 1198S, Streetfighter S
  • Ducati ignition switch on 1199 (switch side)
  • MV Agusta F4-1000 secondary injectors
  • Suzuki ignition switch on GSXR to 05' (switch side, green or black depending on year)
  • <06 YZF-R6 injector harness (main harness side)
  • 06-09 YZF-R6 secondary injector harness (sub-harness side)
spacer
  • Hero FRSH-113
  • Honda 070PZ-002A500
  • KTM 000700000AP (natural)
  • Toyota 90980-10478
QtyPrice
1-5$2.97
6-19$2.82
20-49$2.67
50-99$2.52
100-249$2.38
250-499$2.23
500+$2.08
Quantity:  Kit

6-Way Kit
HMU-6P
6-Way Kit
OEM P/N: 6090-1149
HMU-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Sumitomo
Series: HM Unsealed Series
OEM P/N: 6090-1149
Mating Part: HMU-6S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.30
6-19$2.14
20-49$1.95
50-99$1.84
100+$1.61
Quantity:  Kit

6-Way Kit
HMU-6S
6-Way Kit
OEM P/N: 6090-1218
HMU-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo
Series: HM Unsealed Series
OEM P/N: 6090-1218
Mating Part: HMU-6P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$2.30
6-19$2.14
20-49$1.95
50-99$1.84
100+$1.61
Quantity:  Kit

6-Way Kit
HS-6P-1
6-Way Kit
OEM P/N: 7282-2764-30
HS-6P-1  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals

Mfr: OEM Yazaki
Series: HS 025 Series
OEM P/N: 7282-2764-30
Mating Part: HS-6S-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:2
  • Pitch:3.0mm
  • Row Spacing:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$5.04
6-19$4.79
20-49$4.54
50-99$4.28
100+$4.03
Quantity:  Kit

6-Way Kit
HS-6S-1
6-Way Kit
OEM P/N: 7283-2764-30
HS-6S-1  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: OEM Yazaki
Series: HS 025 Series
OEM P/N: 7283-2764-30
Mating Part: HS-6P-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:2
  • Pitch:3.0mm
  • Row Spacing:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.29
6-19$4.08
20-49$3.86
50-99$3.65
100+$3.43
Quantity:  Kit

6-Way Kit
HS-6S-2
6-Way Kit
OEM P/N: 7287-1380-30
HS-6S-2  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: OEM Yazaki
Series: HS 025 Series
OEM P/N: 7287-1380-30
Mating Part: N/A, device only

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.30 - 0.85 mm2
  • Number of Rows:1
  • Pitch:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Mopar 68335241AA repair kit connector
QtyPrice
1-5$4.87
6-19$4.63
20-49$4.38
50-99$4.14
100+$3.90
Quantity:  Kit

6-Way Kit
HVG-6P
6-Way Kit
OEM P/N: 6188-4908
HVG-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals

Mfr: OEM Sumitomo
Series: HV/HVG Sealed Series
OEM P/N: 6188-4908
Mating Part: HVG-6S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:2
  • Pitch:4.1mm
  • Row Spacing:5.2mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$5.10
6-19$4.84
20-49$4.59
50-99$4.33
100+$4.08
Quantity:  Kit

6-Way Kit
HVG-6S
6-Way Kit
OEM P/N: 6189-7040
HVG-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals, TPA lock

Mfr: OEM Sumitomo
Series: HV/HVG Sealed Series
OEM P/N: 6189-7040
Part Name: HVG4-S6FAY-B
Mating Part: HVG-6P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:2
  • Pitch:4.1mm
  • Row Spacing:5.2mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$5.45
6-19$5.18
20-49$4.91
50-99$4.63
100+$4.36
Quantity:  Kit

6-Way Kit
HW-6P
6-Way Kit
OEM P/N: 6181-0074
HW-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals, TPA lock

Mfr: OEM Sumitomo
Series: HW Sealed Series
OEM P/N: 6181-0074
Mating Part: HW-6S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.87
6-19$3.68
20-49$3.48
50-99$3.29
100+$3.10
Quantity:  Kit

6-Way Kit
HW-6S
6-Way Kit
OEM P/N: 6189-0133
HW-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals, TPA lock

Mfr: OEM Sumitomo
Series: HW Sealed Series
OEM P/N: 6189-0133
Mating Part: HW-6P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:NBR
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.82
6-19$3.63
20-49$3.44
50-99$3.25
100+$3.06
Quantity:  Kit

6-Way Kit
HX040-6S
6-Way Kit
OEM P/N: 6189-1012
HX040-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals, front lock

Mfr: OEM Sumitomo
Series: HX 040 Sealed Series
OEM P/N: 6189-1012
Part Name: HX4-DCV6FAY-B
Mating Part: HX040-6P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.1mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$5.68
6-19$5.28
20-49$4.83
50-99$4.54
100+$3.98
Quantity:  Kit

6-Way Kit
JWPF-6P
6-Way Kit
OEM P/N: 06T-JWPF-VSLE-D
JWPF-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts for 26-22 AWG wire

Mfr: OEM JST
Series: JWPF Series
OEM P/N: 06T-JWPF-VSLE-D
Mating Part: JWPF-6S

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.13 - 0.35 mm2
  • Number of Rows:2
  • Pitch:2.0mm
  • Row Spacing:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-55 - 85 °C
  • Protection Rating:IPX7
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Harley Davidson 69201163
QtyPrice
1-5$4.59
6-19$4.36
20-49$4.13
50-99$3.90
100+$3.67
Quantity:  Kit

6-Way Kit
JWPF-6S
6-Way Kit
OEM P/N: 06R-JWPF-VSLE-D
JWPF-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts for 26-22 AWG wire

Mfr: OEM JST
Series: JWPF Series
OEM P/N: 06R-JWPF-VSLE-D
Mating Part: JWPF-6P

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.13 - 0.35 mm2
  • Number of Rows:2
  • Pitch:2.0mm
  • Row Spacing:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-55 - 85 °C
  • Protection Rating:IPX7
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Various Ducati and KTM
spacer
  • Harley Davidson 69201162
QtyPrice
1-5$3.55
6-19$3.37
20-49$3.19
50-99$3.02
100+$2.84
Quantity:  Kit

6-Way Kit (8-Way with cavities 6 and 7 blocked)
JWPF-8P-MOD1
6-Way Kit (8-Way with cavities 6 and 7 blocked)
OEM P/N: 06(8-67)T-JWPF-VHN-D-M
JWPF-8P-MOD1  6-Way Kit (8-Way with cavities 6 and 7 blocked)
Kit Contents: Housing, 6 pin contacts for 26-22 AWG wire

Mfr: OEM JST
Series: JWPF Series
OEM P/N: 06(8-67)T-JWPF-VHN-D-M
Mating Part: 06(8-67)R-JWPF-VHL-E-D

Note: The housing is the same as JWPF-8P, but has cavities 6 and 7 blocked by the rear seal. JWPF-8S is compatible with this connector.

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.13 - 0.35 mm2
  • Number of Rows:2
  • Pitch:2.0mm
  • Row Spacing:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
Environmental
  • Temp Range[2]:-55 - 85 °C
  • Protection Rating:IPX7
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.31
6-19$4.09
20-49$3.88
50-99$3.66
100+$3.45
Quantity:  Kit

6-Way Kit
MLC040-6P
6-Way Kit
OEM P/N: 345178-2, Black
MLC040-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Tyco/AMP
Series: Multilock 040 Series
OEM P/N: 345178-2, Black
Part Name: 040 SERIES CAP HSG. 6 POSMULTI
Mating Part: MLC040-6S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 0.50 mm2
  • Number of Rows:1
  • Pitch:2.5mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:5A
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.13
6-19$2.97
20-49$2.82
50-99$2.66
100+$2.50
Quantity:  Kit

6-Way Kit
MLC040-6S
6-Way Kit
OEM P/N: 175507-2, Black (superseded by 776204-2)
MLC040-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: OEM Tyco/AMP
Series: Multilock 040 Series
OEM P/N: 175507-2, Black (superseded by 776204-2)
Part Name: 6POS PLUG HSG,.040 SERIES BLK
Mating Part: MLC040-6P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 0.50 mm2
  • Number of Rows:1
  • Pitch:2.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:5A
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Maserati 673004842 repair kit connector
  • Mopar 05183472AA repair kit connector
QtyPrice
1-5$2.02
6-19$1.88
20-49$1.72
50-99$1.62
100+$1.41
Quantity:  Kit

6-Way Kit Ver. 1
MLC070-6P-1
6-Way Kit Ver. 1
OEM P/N: White: 174930-1, Black: 174930-2
MLC070-6P-1  6-Way Kit Ver. 1
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Tyco/AMP
Series: Multilock 070 Series
OEM P/N: White: 174930-1, Black: 174930-2
Part Name: 070 MLC W-W CAP HSG 6P SGL
Mating Part: MLC070-6S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:1.8mm (.070)
  • Wire Size:0.20 - 1.25 mm2
  • Number of Rows:1
  • Pitch:3.5mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:19A
  • Voltage Rating:12V DC
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford F50B-14A459-KA (white)
  • Harley Davidson 73106-96BK
QtyPrice
1-5$3.48
6-19$3.24
20-49$2.96
50-99$2.78
100+$2.44
Quantity:  Kit

6-Way Kit Ver. 2
MLC070-6P-2
6-Way Kit Ver. 2
OEM P/N: White: 175657-1
MLC070-6P-2  6-Way Kit Ver. 2
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Tyco/AMP
Series: Multilock 070 Series
OEM P/N: White: 175657-1
Part Name: 070 MLC W-W CAP HSG 6P
Mating Part: MLC070-6S-2

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:1.8mm (.070)
  • Wire Size:0.20 - 1.25 mm2
  • Number of Rows:2
  • Pitch:3.5mm
  • Row Spacing:5.9mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:19A
  • Voltage Rating:12V DC
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$5.97
6-19$5.55
20-49$5.07
50-99$4.78
100+$4.18
Quantity:  Kit

6-Way Kit
MT-6P-1
6-Way Kit
OEM P/N: 6188-0382
MT-6P-1  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals

Mfr: Aftermarket Sumitomo
Series: MT Sealed Series
OEM P/N: 6188-0382
Part Name: W0906MASSY
Mating Part: MT-6S-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.17
6-19$2.95
20-49$2.69
50-99$2.54
100+$2.22
Quantity:  Kit

6-Way Kit
MT-6P-1-CLIP
6-Way Kit
OEM P/N: 6187-6561
MT-6P-1-CLIP  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6187-6561
Part Name: WP0906MCLASSY
Mating Part: MT-6S-1
Features integral clamp for 7mm dia., 0.7~2.2mm thickness hole.

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Dealer mode connector on many Suzuki motorcycles (white)
  • Suzuki ignition switch on GSXR 05-13' (harness side, grey)
spacer
  • Hero FRS-112N
  • KTM 000700000HE
QtyPrice
1-5$7.21
6-19$6.71
20-49$6.13
50-99$5.77
100+$5.05
Quantity:  Kit

6-Way Kit
6-Way Kit 360 iconspacer
MT-6P-2
6-Way Kit
OEM P/N: 6189-6171
MT-6P-2  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6189-6171
Mating Part: MT-6S-2
Similar to HM-6P, but without bracket mount on bottom of connector.

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ducati DTC on 1198S, Streetfighter S
  • MV Agusta F4-1000 secondary injectors
  • <06 YZF-R6 injector harness (sub-harness side)
  • 06-09 YZF-R6 secondary injector harness (main harness side)
spacer
  • KTM 000700000BH (natural)
QtyPrice
1-5$3.29
6-19$3.13
20-49$2.96
50-99$2.80
100-249$2.63
250-499$2.47
500+$2.30
Quantity:  Kit

6-Way Kit
MT-6S-1
6-Way Kit
OEM P/N: 6180-6771
MT-6S-1  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6180-6771
Part Name: WP0906F
Mating Part: MT-6P-1, MT-6P-1-CLIP

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Suzuki ignition switch on GSXR 05-13' (switch side, grey)
  • Dealer mode connector on many Suzuki motorcycles (white)
spacer
  • Hero FRS-113N
  • KTM 000700000HD
  • Toyota 90980-10651 (White)
QtyPrice
1-5$3.61
6-19$3.36
20-49$3.07
50-99$2.89
100+$2.53
Quantity:  Kit

6-Way Kit
MT-6S-2
6-Way Kit
OEM P/N: 6180-6181
MT-6S-2  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: OEM Sumitomo
Series: MT Sealed Series
OEM P/N: 6180-6181
Mating Part: MT-6P-2 and HM-6P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ducati DTC on 1198S, Streetfighter S
  • Ducati ignition switch on 1199 (switch side)
  • MV Agusta F4-1000 secondary injectors
  • Suzuki ignition switch on GSXR to 05' (switch side, green or black depending on year)
  • GSXR-1000 Tip over sensor on 05-08 (harness side, natural)
  • GSXR-1300 Tip over sensor on 08-09 (harness side, natural)
  • <06 YZF-R6 injector harness (main harness side)
  • 06-09 YZF-R6 secondary injector harness (sub-harness side)
spacer
  • KTM 000700000AP (natural)
  • Toyota 90980-10478
QtyPrice
1-5$3.50
6-19$3.33
20-49$3.15
50-99$2.98
100-249$2.80
250-499$2.62
500+$2.45
Quantity:  Kit

6-Way Kit
MT-6S-3
6-Way Kit
OEM P/N: 6189-0029
MT-6S-3  6-Way Kit
Kit Contents: Housing, 6 socket contacts, 6 seals

Mfr: Aftermarket Sumitomo
Series: MT Sealed Series
OEM P/N: 6189-0029
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.70 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.96
6-19$4.61
20-49$4.22
50-99$3.97
100+$3.47
Quantity:  Kit

6-Way Kit
MTU.IL-6P
6-Way Kit
OEM P/N: 7122-1360
MTU.IL-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: MT Unsealed Interlocking, 090 Unsealed
OEM P/N: 7122-1360
Mating Part: MTU.IL-6S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Clip Slot
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-10384
QtyPrice
1-5$2.19
6-19$2.04
20-49$1.86
50-99$1.75
100+$1.53
Quantity:  Kit

6-Way Kit
MTU.IL-6S
6-Way Kit
OEM P/N: 6244-5061, 7123-1360
MTU.IL-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: MT Unsealed Interlocking, 090 Unsealed
OEM P/N: 6244-5061, 7123-1360
Mating Part: MTU.IL-6P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-10414
QtyPrice
1-5$2.04
6-19$1.90
20-49$1.73
50-99$1.63
100+$1.43
Quantity:  Kit

6-Way Kit
MTU.SL-6P-1
6-Way Kit
OEM P/N: 6242-1061, 7122-1460
MTU.SL-6P-1  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: MT Unsealed Semi-Locking, 090 Unsealed
OEM P/N: 6242-1061, 7122-1460
Mating Part: MTU.SL-6S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-10367
QtyPrice
1-5$2.36
6-19$2.19
20-49$2.01
50-99$1.89
100+$1.65
Quantity:  Kit

6-Way Kit
MTU.SL-6S-1
6-Way Kit
OEM P/N: 6242-5061, 7123-1460
MTU.SL-6S-1  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: MT Unsealed Semi-Locking, 090 Unsealed
OEM P/N: 6242-5061, 7123-1460
Mating Part: MTU.SL-6P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-10366
QtyPrice
1-5$2.21
6-19$2.06
20-49$1.88
50-99$1.77
100+$1.55
Quantity:  Kit

6-Way Kit
MTW-6P
6-Way Kit
OEM P/N: 6030-6991
MTW-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: Aftermarket Sumitomo
Series: MTW Series
OEM P/N: 6030-6991
Mating Part: MTW-6S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • CBR600 F4i, <07' CBR600RR coil sub-harness (black)
spacer
  • Honda 070MZ-0020500 (natural)
  • KTM 000700000GS
QtyPrice
1-5$1.37
6-19$1.27
20-49$1.16
50-99$1.10
100-499$0.96
500-999$0.89
1000-1999$0.82
2000+$0.75
Quantity:  Kit

6-Way Kit
MTW-6S
6-Way Kit
OEM P/N: 6040-6111
MTW-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo
Series: MTW Series
OEM P/N: 6040-6111
Mating Part: MTW-6P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • CBR600 F4i, <07' CBR600RR coil sub-harness (black)
spacer
  • Honda 070MZ-0020400 (natural)
  • KTM 000700000GT
QtyPrice
1-5$1.37
6-19$1.27
20-49$1.16
50-99$1.10
100-499$0.96
500-999$0.89
1000-1999$0.82
2000+$0.75
Quantity:  Kit

6-Way Kit
MTW.NL-6P
6-Way Kit
OEM P/N: 6130-0560
MTW.NL-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: Aftermarket Sumitomo
Series: MTW Series
OEM P/N: 6130-0560
Mating Part: MTW.NL-6S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:ABS
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$1.63
6-19$1.52
20-49$1.39
50-99$1.30
100+$1.14
Quantity:  Kit

6-Way Kit
MTW.NL-6S
6-Way Kit
MTW.NL-6S  6-Way Kit
Kit Contents: Housing, 6 socket contacts

Mfr: Aftermarket Sumitomo
Series: MTW Series
Mating Part: MTW.NL-6P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:6
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:5.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:ABS
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$1.60
6-19$1.49
20-49$1.36
50-99$1.28
100+$1.12
Quantity:  Kit

6-Way Kit
MX150-6P-2A
6-Way Kit
OEM P/N: 33482-3601, supersedes 33482-0601
MX150-6P-2A  6-Way Kit
Kit Contents: Housing, 6 pin contacts

Mfr: OEM Molex
Series: MX150 Sealed Series
OEM P/N: 33482-3601, supersedes 33482-0601
Keying: A
Mating Part: MX150-6S-2A

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:6
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 2.00 mm2
  • Number of Rows:2
  • Pitch:3.5mm
  • Row Spacing:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:SPS/PA+GF20
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford 5W7T-14A624-EB
  • Harley Davidson 72188-07BK
QtyPrice
1-5$4.44
6-19$4.22
20-49$4.00
50-99$3.77
100+$3.55
Quantity:  Kit

6-Way Kit
RFW-6P
6-Way Kit
RFW-6P  6-Way Kit
Kit Contents: Housing, 6 pin contacts, 6 seals, lock

Mfr: Aftermarket Furukawa
Series: RFW Series
Mating Part: RFW-6S
P/N:
Natural (White), FW-C-6M (alt p/n: 12445-5206)
Black, FW-C-6M-B (alt p/n: P010497, 12445-5206-2)

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:5.8mm
  • Row Spacing:5.5mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:14A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$3.74
6-19$3.55
20-49$3.37
50-99$3.18
100+$2.99
Quantity:  Kit

6-Way Kit
TS025-6P-1
6-Way Kit
OEM P/N: 6188-0706 Natural (In stock) 6188-4966 Black
TS025-6P-1  6-Way Kit
Kit Contents: Housing, 6 pin contacts for 24-20 awg wire, 6 seals

Mfr: OEM Sumitomo
Series: TS 025 Sealed Series
OEM P/N: 6188-0706 Natural (In stock) 6188-4966 Black
Part Name: 12381WQA06M-NA
Mating Part: TS025-6S-1

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:6
  • Contact Size:0.64mm (.025)
  • Wire Size:0.22 - 0.50 mm2
  • Number of Rows:3
  • Pitch:3.0mm
  • Row Spacing:3.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:7A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Toyota 90980-12381
QtyPrice
1-5$4.62
6-19$4.39
20-49$4.16
50-99$3.93
100+$3.70
Quantity:  Kit


Facebook link spacer Instagram link spacer LinkedIn link spacer Twitter link spacer Twitter link
Privacy Notice | Terms and Conditions | Site Map
© 2009-2025 Corsa Technic, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
R6A1
R7A4
R7A3
R7A2
