New Items

25-Way (21+4) Hybrid Kit
025IIU/090IIU-25P

025IIU/090IIU-25P
25-Way (21+4) Hybrid Kit
OEM P/N: Gray: 7282-4855-40

025IIU/090IIU-25P 25-Way (21+4) Hybrid Kit
Kit Contents: Housing, 21x 025 pin contacts, 4x 090 pin contacts

Mfr: OEM Yazaki
Series: 025II+090II Hybrid Unsealed
OEM P/N: Gray: 7282-4855-40
Mating Part: 025IIU/090IIU-25S

General

Sealing:Unsealed
Number of Ways:25
Contact Size:Mixed
Wire Size:0.22 - 2.00 mm²
Number of Rows:3
Pitch:Multiple
Row Spacing:Multiple
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Toyota 90980-12413

25-Way (21+4) Hybrid Kit
025IIU/090IIU-25S

025IIU/090IIU-25S
25-Way (21+4) Hybrid Kit
OEM P/N: Gray: 7283-4855-40

View Item

025IIU/090IIU-25S 25-Way (21+4) Hybrid Kit
Kit Contents: Housing, 21x 025 socket contacts for 22-20awg wire, 4x 090 socket contacts

Mfr: OEM Yazaki
Series: 025II+090II Hybrid Unsealed
OEM P/N: Gray: 7283-4855-40
Mating Part: 025IIU/090IIU-25P

General

Sealing:Unsealed
Number of Ways:25
Contact Size:Mixed
Wire Size:0.22 - 2.00 mm²
Number of Rows:3
Pitch:Multiple
Row Spacing:Multiple
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
For mixed signal, or hybrid connectors, the current rating listed is for the larger (power) contact size.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Toyota 90980-12414

2-Way Kit
050U-2P-2

050U-2P-2
2-Way Kit
OEM P/N: 4G0210-0001

View Item

050U-2P-2 2-Way Kit
Kit Contents: Housing, 2 pin contacts for 22-20 AWG wire

Mfr: OEM Tokai Rika
Series: 050 Unsealed
OEM P/N: 4G0210-0001
Mating Part: 050U-2S-2

For 7 x 12mm hole with 2.5mm max. thickness

General

Sealing:Unsealed
Number of Ways:2
Contact Size:1.3mm (.050)
Wire Size:0.30 - 0.50 mm²
Number of Rows:1
Pitch:2.5mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Clip
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:3A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Sumitomo 1300-4764
Toyota 90980-11367
Yazaki 7282-4328

2-Way Kit
050U-2S-2

050U-2S-2
2-Way Kit
OEM P/N: 4F0280-0000

View Item

050U-2S-2 2-Way Kit
Kit Contents: Housing, 2 socket contacts for 22-20 AWG wire

Mfr: OEM Tokai Rika
Series: 050 Unsealed
OEM P/N: 4F0280-0000
Mating Part: 050U-2P-2

General

Sealing:Unsealed
Number of Ways:2
Contact Size:1.3mm (.050)
Wire Size:0.30 - 0.50 mm²
Number of Rows:1
Pitch:2.5mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:3A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Sumitomo 1300-4941, 1300-8546
Toyota 90980-11436
Yazaki 7283-4328

10-Way Kit
090IIU-10P-1

090IIU-10P-1
10-Way Kit
OEM P/N: 6249-1235, 7282-1305

View Item

090IIU-10P-1 10-Way Kit
Kit Contents: Housing, 10 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6249-1235, 7282-1305
Part Name: 11536N9A10M-NA
Mating Part: 090IIU-10S-1

General

Sealing:Unsealed
Number of Ways:10
Contact Size:2.3mm (.090)
Wire Size:0.30 - 2.00 mm²
Number of Rows:2
Pitch:4.0mm
Row Spacing:5.0mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Toyota 90980-11536, 90980-11823, 90980-12481

10-Way Kit
090IIU-10S-1

090IIU-10S-1
10-Way Kit
OEM P/N: 6248-5276, 7283-1305

View Item

090IIU-10S-1 10-Way Kit
Kit Contents: Housing, 10 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6248-5276, 7283-1305
Part Name: 11537N9A10F-NA
Mating Part: 090IIU-10P-1

General

Sealing:Unsealed
Number of Ways:10
Contact Size:2.3mm (.090)
Wire Size:0.30 - 2.00 mm²
Number of Rows:2
Pitch:4.0mm
Row Spacing:5.0mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Toyota 90980-11537, 90980-11817, 90980-12338, 90980-12350

4-Way Kit
250.ET-4P

250.ET-4P
4-Way Kit
OEM P/N: 6070-4471

View Item

250.ET-4P 4-Way Kit
Kit Contents: Housing, 4 pin contacts

Mfr: Aftermarket Sumitomo
Series: 250 ET Type
OEM P/N: 6070-4471
Part Name: ET04-1W
Mating Part: 250.ET-4S

Drawing (S-5822_7.pdf)

General

Sealing:Unsealed
Number of Ways:4
Contact Size:6.3mm (.250)
Wire Size:0.30 - 3.00 mm²
Number of Rows:2
Pitch:9.0mm
Row Spacing:5.5mm
Numbered Cavities:No

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PA66
Mounting Style:Free hanging
TPA:No
CPA:No

Electrical

Current Rating^[1]:20A

Environmental

Temp Range^[2]:-40 - 120 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

4-Way Kit
250.ET-4S

250.ET-4S
4-Way Kit
OEM P/N: 6070-4481

View Item

250.ET-4S 4-Way Kit
Kit Contents: Housing, 4 socket contacts

Mfr: Aftermarket Sumitomo
Series: 250 ET Type
OEM P/N: 6070-4481
Part Name: ET04-2W
Mating Part: 250.ET-4P

Drawing (S-5770_6.pdf)

General

Sealing:Unsealed
Number of Ways:4
Contact Size:6.3mm (.250)
Wire Size:0.30 - 3.00 mm²
Number of Rows:2
Pitch:9.0mm
Row Spacing:5.5mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PA66
Mounting Style:Free hanging
TPA:No
CPA:No

Electrical

Current Rating^[1]:20A

Environmental

Temp Range^[2]:-40 - 120 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

4-Way Kit
58M-4S-LIS

58M-4S-LIS
4-Way Kit
OEM P/N: Sumitomo: 1300-6049
Yazaki: 7223-6144-90

View Item

58M-4S-LIS 4-Way Kit
Kit Contents: Housing, 4 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: Sumitomo: 58 M Unsealed, Yazaki: 58 M Unsealed
OEM P/N: Sumitomo: 1300-6049
Yazaki: 7223-6144-90
Part Name: M04FL-IS
Mating Part: N/A, device only

General

Sealing:Unsealed
Number of Ways:4
Contact Size:6.3mm (.250)
Wire Size:0.30 - 5.00 mm²
Number of Rows:3
Pitch:Multiple
Row Spacing:Multiple
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PP
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:25A

Environmental

Temp Range^[2]:-40 - 125 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

10-Way Kit
58S-10S-1

58S-10S-1
10-Way Kit
OEM P/N: 6100-6101, 7123-1700

View Item

58S-10S-1 10-Way Kit
Kit Contents: Housing, 10 socket contacts, rear lock

Mfr: Aftermarket Yazaki
Series: 58 S Unsealed
OEM P/N: 6100-6101, 7123-1700
Part Name: S10FW
Mating Part: 6100-1101, 7122-1700

General

Sealing:Unsealed
Number of Ways:10
Contact Size:2.8mm (.110)
Wire Size:0.30 - 2.00 mm²
Number of Rows:2
Pitch:5.8mm
Row Spacing:4.9mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PA66
Mounting Style:Free hanging
TPA:Yes, separate/loose item
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 100 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

2-Way Kit
58S-2S-2

58S-2S-2
2-Way Kit
OEM P/N: 6100-5025, 7123-1629-90

View Item

58S-2S-2 2-Way Kit
Kit Contents: Housing, 2 socket contacts, rear lock

Mfr: OEM Sumitomo, Yazaki
Series: 58 S Unsealed, 58 S Unsealed
OEM P/N: 6100-5025, 7123-1629-90
Part Name: S02FL
Mating Part: 7122-1629-90, S02ML

General

Sealing:Unsealed
Number of Ways:2
Contact Size:2.8mm (.110)
Wire Size:0.30 - 2.00 mm²
Number of Rows:1
Pitch:4.9mm
Numbered Cavities:Yes, Polarity

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PA6
Mounting Style:Free hanging
TPA:Yes, separate/loose item
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 100 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

4-Way Kit
58W-4P

58W-4P
4-Way Kit
OEM P/N: 7122-1844-40

View Item

58W-4P 4-Way Kit
Kit Contents: Housing, 4 pin contacts, 4 seals, rear holder/lock

Mfr: OEM Yazaki
Series: Sumitomo: 58 W Sealed, Yazaki: 58 W Sealed
OEM P/N: 7122-1844-40
Part Name: W04MW
Mating Part: 58W-4S

General

Sealing:Single Wire Sealed
Number of Ways:4
Contact Size:2.8mm (.110)
Wire Size:0.30 - 2.00 mm²
Number of Rows:2
Pitch:6.8mm
Row Spacing:6.8mm
Numbered Cavities:No

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PA66
Mounting Style:Clip Slot
TPA:Yes, separate/loose item
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 125 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

4-Way Kit
58W-4S

58W-4S
4-Way Kit
OEM P/N: 7223-1844-40

View Item

58W-4S 4-Way Kit
Kit Contents: Housing, 4 socket contacts, 4 seals, rear holder/lock

Mfr: OEM Yazaki
Series: Sumitomo: 58 W Sealed, Yazaki: 58 W Sealed
OEM P/N: 7223-1844-40
Part Name: W04FW
Mating Part: 58W-4P

General

Sealing:Single Wire Sealed
Number of Ways:4
Contact Size:2.8mm (.110)
Wire Size:0.30 - 2.00 mm²
Number of Rows:2
Pitch:6.8mm
Row Spacing:6.8mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PA66
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:Yes, separate/loose item
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 125 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

1-Way Kit
58Y-1P

58Y-1P
1-Way Kit
OEM P/N: 7222-4210-40

View Item

58Y-1P 1-Way Kit
Kit Contents: Housing, 1 pin contact, 1 seal for 3.6-4.4mm ins.

Mfr: OEM Yazaki
Series: 58 Y Type
OEM P/N: 7222-4210-40
Part Name: Y01MGY
Mating Part: 58Y-1S

General

Sealing:Single Wire Sealed
Number of Ways:1
Contact Size:9.5mm (.375)
Wire Size:3.00 - 8.00 mm²
Number of Rows:1
Numbered Cavities:No

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Seal Material:Silicone Rubber
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:40A

Environmental

Temp Range^[2]:-40 - 120 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

1-Way Kit
58Y-1S

58Y-1S
1-Way Kit
OEM P/N: 7123-4210-40

View Item

58Y-1S 1-Way Kit
Kit Contents: Housing, 1 socket contact, 1 seal for 3.6-4.4mm ins.

Mfr: OEM Yazaki
Series: 58 Y Type
OEM P/N: 7123-4210-40
Part Name: Y01FGY
Mating Part: 58Y-1P

General

Sealing:Single Wire Sealed
Number of Ways:1
Contact Size:9.5mm (.375)
Wire Size:0.85 - 8.00 mm²
Number of Rows:1
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:40A

Environmental

Temp Range^[2]:-40 - 120 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

2-Way Kit
58Y-2S

58Y-2S
2-Way Kit
OEM P/N: 7123-4220-40

View Item

58Y-2S 2-Way Kit
Kit Contents: Housing, 2 socket contacts, 2 seals for 3.6-4.4mm ins., TPA

Mfr: OEM Yazaki
Series: 58 Y Type
OEM P/N: 7123-4220-40
Part Name: Y02FGY
Mating Part: 7222-4220-40

General

Sealing:Single Wire Sealed
Number of Ways:2
Contact Size:9.5mm (.375)
Wire Size:0.85 - 8.00 mm²
Number of Rows:1
Pitch:11.0mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:Yes, separate/loose item
CPA:No

Electrical

Current Rating^[1]:40A

Environmental

Temp Range^[2]:-40 - 120 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

10-Way Kit
62C-10S-2

62C-10S-2
10-Way Kit
OEM P/N: Furukawa PH855-10050, Yazaki 7123-7902-80

View Item

62C-10S-2 10-Way Kit
Kit Contents: Housing, 10 socket terminals for 20-18awg wire

Mfr: Aftermarket Furukawa, Sumitomo, Yazaki
Series: 62 C-Type, 62 C-Type, 62 C-Type
OEM P/N: Furukawa PH855-10050, Yazaki 7123-7902-80
Part Name: C10FBR
Mating Part: N/A, device only

General

Sealing:Unsealed
Number of Ways:10
Contact Size:1.5mm (.060)
Wire Size:0.20 - 0.85 mm²
Number of Rows:1
Pitch:3.3mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:6A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

2-Way Kit
62C-2S-2

62C-2S-2
2-Way Kit
OEM P/N: Furukawa PH855-02020, Yazaki 7123-7821-30

View Item

62C-2S-2 2-Way Kit
Kit Contents: Housing, 2 socket terminals for 20-18awg wire

Mfr: Aftermarket Furukawa, Sumitomo, Yazaki
Series: 62 C-Type, 62 C-Type, 62 C-Type
OEM P/N: Furukawa PH855-02020, Yazaki 7123-7821-30
Part Name: C02FB
Mating Part: PH851-02020, 7122-7821-30

General

Sealing:Unsealed
Number of Ways:2
Contact Size:1.5mm (.060)
Wire Size:0.20 - 0.85 mm²
Number of Rows:1
Pitch:12.0mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:6A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

KET MG611272

3-Way Kit
62C-3S-1

62C-3S-1
3-Way Kit
OEM P/N: Furukawa PH855-03010, Yazaki 7123-7830

View Item

62C-3S-1 3-Way Kit
Kit Contents: Housing, 3 socket terminals for 20-18awg wire

Mfr: Furukawa, Sumitomo, OEM Yazaki
Series: 62 C-Type, 62 C-Type, 62 C-Type
OEM P/N: Furukawa PH855-03010, Yazaki 7123-7830
Part Name: C03FW
Mating Part: PH851-03010, 7122-7830

General

Sealing:Unsealed
Number of Ways:3
Contact Size:1.5mm (.060)
Wire Size:0.20 - 0.85 mm²
Number of Rows:1
Pitch:3.3mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:6A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

KET MG611297

4-Way Kit
62C-4S-1

62C-4S-1
4-Way Kit
OEM P/N: Furukawa PH855-04010, Yazaki 7123-7840

View Item

62C-4S-1 4-Way Kit
Kit Contents: Housing, 4 socket terminals for 20-18awg wire

Mfr: Aftermarket Furukawa, Sumitomo, Yazaki
Series: 62 C-Type, 62 C-Type, 62 C-Type
OEM P/N: Furukawa PH855-04010, Yazaki 7123-7840
Part Name: C04FW
Mating Part: PH851-04010, 7122-7840

General

Sealing:Unsealed
Number of Ways:4
Contact Size:1.5mm (.060)
Wire Size:0.20 - 0.85 mm²
Number of Rows:1
Pitch:3.3mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:6A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

KET MG611275

AS Micro MK3 #23 Pin Contact
AS-SZ23-PIN

AS-SZ23-PIN
AS Micro MK3 #23 Pin Contact
OEM P/N: 604927-31

View Item

AS-SZ23-PIN AS Micro MK3 #23 Pin Contact

Mfr: Deutsch
Series: AS Micro HE (AS), AS Micro Lite HE (ASL)
OEM P/N: 604927-31

Contact size: 23, Wire size: 28-22 awg

General

Sealing:Matte Sealed
Contact Size:Size 23
Wire Size:0.05 - 0.35 mm²

Mechanical

Contact Type:Pin, circular
Lance Type:Housing Lance

Electrical

Current Rating^[1]:3A

Environmental

Temp Range^[2]:-40 - 150 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

CMX Series Socket Contact
CMX-SKT

CMX-SKT
CMX Series Socket Contact
OEM P/N: 1211A1570

View Item

CMX-SKT CMX Series Socket Contact

Mfr: KST
Series: CMX Series
OEM P/N: 1211A1570

For 0.3 mm² (22 AWG) wire

General

Sealing:Single Wire Sealed
Contact Size:0.64mm (.025)
Wire Size:0.30 - 0.30 mm²

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance

Electrical

Current Rating^[1]:2A

Environmental

Temp Range^[2]:-40 - 85 °C
Protection Rating:IPX4

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

12-Way Kit
DL090-12S

DL090-12S
12-Way Kit
OEM P/N: 6195-0149

View Item

DL090-12S 12-Way Kit
Kit Contents: Housing, 12 socket contacts, 12 seals

Mfr: OEM Sumitomo
Series: DL 090 Sealed Series
OEM P/N: 6195-0149
Part Name: W-DL09ASY12F-D2
Mating Part: 6195-0152

General

Sealing:Single Wire Sealed
Number of Ways:12
Contact Size:2.3mm (.090)
Wire Size:0.30 - 2.00 mm²
Number of Rows:3
Pitch:Multiple
Row Spacing:5.5mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Seal Material:Silicone Rubber
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:22A

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

4-Way Kit
HX090-4S-1

HX090-4S-1
4-Way Kit
OEM P/N: 6189-0617

View Item

HX090-4S-1 4-Way Kit
Kit Contents: Housing, 4 socket contacts, 4 seals, front lock

Mfr: OEM Sumitomo
Series: HX 090 Sealed Series
OEM P/N: 6189-0617
Part Name: HX9DC-4FAY-B
Mating Part: N/A, device only

3D STEP (6189-0617.zip)
See related terminal for crimp specs
Series Catalog (HX090-CAT_4-2024.pdf)

General

Sealing:Single Wire Sealed
Number of Ways:4
Contact Size:2.3mm (.090)
Wire Size:0.30 - 2.00 mm²
Number of Rows:1
Pitch:Multiple
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:Yes, separate/loose item
CPA:No

Electrical

Current Rating^[1]:22A

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

5-Way Kit
ILAG5-5S

ILAG5-5S
5-Way Kit
OEM P/N: IL-AG5-5S-S3C1

View Item

ILAG5-5S 5-Way Kit
Kit Contents: Housing, 5x socket contacts

Mfr: OEM JAE
Series: IL-AG5 Series
OEM P/N: IL-AG5-5S-S3C1
Mating Part: Pin header

For .3-.85 mm² (22-18 AWG) wire, with 1.4-2.4mm (.055-.094") insulation dia.

General

Sealing:Unsealed
Number of Ways:5
Contact Size:0.64mm (.025)
Wire Size:0.30 - 0.85 mm²
Number of Rows:1
Pitch:2.5mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Terminal Lance
Housing Material:PBT
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:3A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

2-Way Kit
ILAG9-2P

ILAG9-2P
2-Way Kit
OEM P/N: IL-AG9-2P-S3C1

View Item

ILAG9-2P 2-Way Kit
Kit Contents: Housing, 2x pin contacts

Mfr: OEM JAE
Series: IL-AG9 Series
OEM P/N: IL-AG9-2P-S3C1
Mating Part: ILAG9-2S

For .3-.85 mm² (22-18 AWG) wire, with 1.4-2.4mm (.055-.094") insulation dia.

General

Sealing:Unsealed
Number of Ways:2
Contact Size:0.64mm (.025)
Wire Size:0.30 - 0.85 mm²
Number of Rows:1
Pitch:2.5mm
Numbered Cavities:No

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Terminal Lance
Housing Material:PBT
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:3A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

2-Way Kit, Code 1
KOM1.1A-2S-1

KOM1.1A-2S-1
2-Way Kit, Code 1
OEM P/N: 1 928 403 874 w/standard seal, black (IN STOCK)
1 928 403 876 w/standard seal, brown
1 928 404 655 w/special seal

View Item

KOM1.1A-2S-1 2-Way Kit, Code 1
Kit Contents: Housing, 2 socket contacts for 20-18 AWG wire, 2 seals

Mfr: OEM Bosch
Series: Kompakt 1.1
OEM P/N: 1 928 403 874 w/standard seal, black (IN STOCK)
1 928 403 876 w/standard seal, brown
1 928 404 655 w/special seal
Code: 1
Mating Part: KOM1-2P-1

General

Sealing:Single Wire Sealed
Number of Ways:2
Contact Size:2.8mm (.110)
Wire Size:0.35 - 2.50 mm²
Number of Rows:1
Pitch:5.0mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Terminal Lance
Housing Material:PA66+GF
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:No
CPA:No

Electrical

Current Rating^[1]:12A
Voltage Rating:40V

Environmental

Temp Range^[2]:-40 - 150 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Mopar 05143779AB repair kit connector (w/std seal)
Nissan/Bosch J-48817-1121 pigtail connector
Nissan service part 24008-9DK3B connector

3-Way Kit
MP150P-3P

MP150P-3P
3-Way Kit
OEM P/N: 410027

View Item

MP150P-3P 3-Way Kit
Kit Contents: Housing, 3 pin contacts, rear seal

Mfr: Aftermarket Delphi
Series: Not technically part of these series, but is an applicable mate to a connector of these series: GT-150 3.5mm CL Sealed Series, Metri-Pack 150 Pull to Seat Series
OEM P/N: 410027
Mating Part: GT150.35-3S-6, MP150P-3S

General

Sealing:Matte Sealed
Number of Ways:3
Contact Size:1.5mm (.060)
Wire Size:0.35 - 1.00 mm²
Number of Rows:2
Pitch:3.5mm
Row Spacing:3.4mm
Numbered Cavities:Yes, Alphabetically

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Terminal Lance
Housing Material:PBT+GF
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:No
CPA:No

Electrical

Current Rating^[1]:14A

Environmental

Temp Range^[2]:-40 - 125 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

12-Way Kit, Keying A
SS12-12P-A

SS12-12P-A
12-Way Kit, Keying A
OEM P/N: 807-378-511

View Item

SS12-12P-A 12-Way Kit, Keying A
Kit Contents: Housing, 12 pin contacts, 12 seals

Mfr: OEM Hirschmann
Series: SealStar 1.2mm
OEM P/N: 807-378-511
Keying: A
Mating Part: SS12-12S-A

General

Sealing:Single Wire Sealed
Number of Ways:12
Contact Size:1.2mm (.047)
Wire Size:0.13 - 1.00 mm²
Number of Rows:2
Pitch:4.0mm
Row Spacing:4.0mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Terminal Lance
Housing Material:PA66+GF
Seal Material:Silicone Rubber
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:10A

Environmental

Temp Range^[2]:-40 - 150 °C
Protection Rating:IPX7/IPX9K

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

5-Way Kit
TLC-5S

TLC-5S
5-Way Kit
OEM P/N: 7129-6051

View Item

TLC-5S 5-Way Kit
Kit Contents: Housing, 5 socket contacts for 24-20 awg wire, 5 seals

Mfr: OEM Yazaki
Series: TLC Series
OEM P/N: 7129-6051
Mating Part: 7228-6051, 7228-6052

General

Sealing:Single Wire Sealed
Number of Ways:5
Contact Size:1.0mm (.040)
Wire Size:0.20 - 0.50 mm²
Number of Rows:1
Pitch:3.0mm
Numbered Cavities:No

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:No
CPA:No

Electrical

Current Rating^[1]:3A

Environmental

Temp Range^[2]:-40 - 85 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Toyota 90980-10558

SLK 2.8 Removal Tool, for housings with passive (internal) TPA
TOOL-IRT22

TOOL-IRT22
SLK 2.8 Removal Tool, for housings with passive (internal) TPA
OEM P/N: 680-33183839 RT

View Item

TOOL-IRT22 SLK 2.8 Removal Tool, for housings with passive (internal) TPA

OEM P/N: 680-33183839 RT

For KOSTAL SLK 2.8 contacts, in housings with passive (internal) TPA.
Comparable with:
KOSTAL 2 72 00 54405 0 (w/o ejector function)
Hazet 4674-1
Bosch 11 15 006
APTIV 10714732 / 33282310

This item is backordered.

TS 025 Unsealed Pin Contact
TS025U-PIN

TS025U-PIN
TS 025 Unsealed Pin Contact

View Item

TS025U-PIN TS 025 Unsealed Pin Contact

Mfr: Sumitomo
Series: TS 025 Unsealed, used in Tokai Rika 0.64II (025II) Unsealed, and Yazaki 025II+090II Hybrid Unsealed

	Wire Size	Plating	Part Number
TS025U-PIN1	.13 mm² (26 AWG) .85-.95mm insulation dia.	Tin	8230-4878
-	.13 mm² (26 AWG) .85-.95mm insulation dia.	Gold	8230-5136
TS025U-PIN2	.22-.35 mm² (24-22 AWG) .95-1.2mm insulation dia.	Tin	8100-3622
-	.22-.35 mm² (24-22 AWG) .95-1.2mm insulation dia.	Gold	8100-3626
TS025U-PIN3	.3-.5 mm² (22-20 AWG) 1.1-1.7mm insulation dia.	Tin	8100-3623
-	.3-.5 mm² (22-20 AWG) 1.1-1.7mm insulation dia.	Gold	8100-3627
Available stock: Aftermarket OEM

General

Sealing:Unsealed
Contact Size:0.64mm (.025)
Wire Size:0.13 - 0.50 mm²

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance

Electrical

Current Rating^[1]:7A
Voltage Rating:14V DC

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

Terminal used in Toyota 82998-24270 (PIN3), 82998-24280 (Gold plated, PIN3-Au) repair wire

4-Way Kit
UP16-4P-A

UP16-4P-A
4-Way Kit
OEM P/N: 1F1T-14A624-DA-004

View Item

UP16-4P-A 4-Way Kit
Kit Contents: Housing, 4x pins, TPA

Mfr: OEM Ford
Series: 1.6mm Micropin "Wedgelock"
OEM P/N: 1F1T-14A624-DA-004
Keying: A
Mating Part: UP16-4S-A

Brown seal for 1.19-2.70mm insulation wire

General

Sealing:Matte Sealed
Number of Ways:4
Contact Size:1.58mm (.063)
Wire Size:0.25 - 2.00 mm²
Number of Rows:2
Pitch:4.0mm
Row Spacing:8.0mm
Numbered Cavities:No

Mechanical

Contact Type:Pin, circular
Termination:Open barrel crimp
Lance Type:Housing Lance
Seal Material:Silicone Rubber
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:22A

Environmental

Temp Range^[2]:-40 - 135 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Ford 3U2Z-14S411-HSB, WPT-1008 (Tin greased terminals) pigtail connector
Ford 3U2Z-14S411-APA, WPT-225 (Gold plated terminals, blue housing) pigtail connector
Ford 1F1T-14A624-DA

205 Positive Lock Socket Contact
Y205PL-SKT

Y205PL-SKT
205 Positive Lock Socket Contact
OEM P/N: 7116-7150

View Item

Y205PL-SKT 205 Positive Lock Socket Contact

Mfr: OEM Yazaki
Series: Positive Lock Series
OEM P/N: 7116-7150

For .5-1.25 mm² (20-16 AWG) wire.

Drawing (7116-7150.pdf)

General

Sealing:Unsealed
Contact Size:5.2mm (.205)
Wire Size:0.50 - 1.25 mm²

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance

250 Positive Lock Socket Contact
Y250PL-SKT2

Y250PL-SKT2
250 Positive Lock Socket Contact

View Item

Y250PL-SKT2 250 Positive Lock Socket Contact

Mfr: OEM Yazaki
Series: Positive Lock Series

	Wire Size	Plating	Part Number
Y250PL-SKT1	.2-.5 mm² (22-20 AWG)	Plain Brass	7116-2784
-	.2-.5 mm² (22-20 AWG)	Tin Plated	7116-2784-02
Y250PL-SKT2	.85-2.0 mm² (18-14 AWG)	Plain Brass	7116-2783
-	.85-2.0 mm² (18-14 AWG)	Tin Plated	7116-2783-02
Available stock: Aftermarket OEM

Drawing (7116-2783.pdf)

General

Sealing:Unsealed
Contact Size:6.3mm (.250)
Wire Size:0.20 - 2.00 mm²

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance

2-Way Kit
YESC.15KU-2P-A

YESC.15KU-2P-A
2-Way Kit
OEM P/N: 7282-6443-40

View Item

YESC.15KU-2P-A 2-Way Kit
Kit Contents: Housing, 2 pin contacts

Mfr: OEM Yazaki
Series: YESC KAIZEN 1.5 Unsealed
OEM P/N: 7282-6443-40
Mating Part: YESC.15KU-2S-A

General

Sealing:Unsealed
Number of Ways:2
Contact Size:1.5mm (.060)
Wire Size:0.30 - 1.50 mm²
Number of Rows:1
Pitch:3.5mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Pin, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT+GF
Mounting Style:Clip Slot
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:15A

Environmental

Temp Range^[2]:-40 - 125 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

2-Way Kit
YESC.15KU-2S-A

YESC.15KU-2S-A
2-Way Kit
OEM P/N: 7283-6443-40

View Item

YESC.15KU-2S-A 2-Way Kit
Kit Contents: Housing, 2 socket contacts

Mfr: OEM Yazaki
Series: YESC KAIZEN 1.5 Unsealed
OEM P/N: 7283-6443-40
Mating Part: YESC.15KU-2P-A

General

Sealing:Unsealed
Number of Ways:2
Contact Size:1.5mm (.060)
Wire Size:0.30 - 1.50 mm²
Number of Rows:1
Pitch:3.5mm
Numbered Cavities:Yes, Numbered

Mechanical

Contact Type:Socket, flat
Termination:Open barrel crimp
Lance Type:Housing Lance
Housing Material:PBT+GF
Mounting Style:Free hanging
TPA:Yes
CPA:No

Electrical

Current Rating^[1]:15A

Environmental

Temp Range^[2]:-40 - 125 °C

1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.
