Home ▹ Connectors ▹ By # Of Ways ▹ 3-Way

3-Way

180 Items.  Showing Items 1 thru 50.
 1  2  3  4   Next »   Show All
3-Way Kit
090II-3P-6
3-Way Kit
OEM P/N: 7282-7031-10
090II-3P-6  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7282-7031-10
Mating Part: 090II-3S-6

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:5.8mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-11131
QtyPrice
1-5$4.73
6-19$4.49
20-49$4.26
50-99$4.02
100+$3.78
Quantity:  Kit

3-Way Kit
090II-3S-1
3-Way Kit
OEM P/N: 7283-1133-10 Grey
7283-1133-30 Black
090II-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-1133-10 Grey
7283-1133-30 Black
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-11261 (Black or Grey)
QtyPrice
1-5$6.14
6-19$5.83
20-49$5.53
50-99$5.22
100+$4.91
Quantity:  Kit

3-Way Kit
090II-3S-3
3-Way Kit
OEM P/N: 7283-4534-40
090II-3S-3  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-4534-40
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:HPA
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$5.86
6-19$5.57
20-49$5.27
50-99$4.98
100+$4.69
Quantity:  Kit

3-Way Kit
090II-3S-4
3-Way Kit
OEM P/N: 7283-4535-30
090II-3S-4  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-4535-30

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:HPA
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$6.33
6-19$6.01
20-49$5.70
50-99$5.38
100+$5.06
Quantity:  Kit

3-Way Kit
090II-3S-5
3-Way Kit
OEM P/N: 7283-4536-40
090II-3S-5  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-4536-40

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:HPA
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$6.08
6-19$5.78
20-49$5.47
50-99$5.17
100+$4.86
Quantity:  Kit

3-Way Kit
090II-3S-6
3-Way Kit
OEM P/N: 7283-7031-10
090II-3S-6  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Yazaki
Series: 090II Sealed Series
OEM P/N: 7283-7031-10
Mating Part: 090II-3P-6

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:2
  • Pitch:6.0mm
  • Row Spacing:5.8mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:NBR
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-11132
QtyPrice
1-5$5.71
6-19$5.42
20-49$5.14
50-99$4.85
100+$4.57
Quantity:  Kit

3-Way Kit
090IIU-3P-1
3-Way Kit
OEM P/N: 6520-0492, 7282-1030
090IIU-3P-1  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6520-0492, 7282-1030
Part Name: 11763N9A03M-NA
Mating Part: 090IIU-3S-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:HPA
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Toyota 90980-10907 (Yazaki), 90980-11763 (Sumitomo)
QtyPrice
1-5$2.55
6-19$2.42
20-49$2.29
50-99$2.17
100+$2.04
Quantity:  Kit

3-Way Kit
090IIU-3S-1
3-Way Kit
OEM P/N: 6520-0577, 7283-1030
090IIU-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: OEM Sumitomo, Yazaki
Series: TS 090 Unsealed, 090II Unsealed Series
OEM P/N: 6520-0577, 7283-1030
Part Name: 11764N9A03F-NA
Mating Part: 090IIU-3P-1

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:4.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:HPA
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Mopar 68064999AA repair kit connector
  • Toyota 90980-10908, 90980-11764, 90980-12255, 90980-12473
QtyPrice
1-5$2.44
6-19$2.32
20-49$2.20
50-99$2.07
100+$1.95
Quantity:  Kit

3-Way Kit
250.ARM-3P
3-Way Kit
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7122-2137-30 (PA66), 7122-2237-30 (PP)
Natural | 6111-2556 (PA66), 6070-3381 (PP) | 7122-2137 (PA66), 7122-2237 (PP)
250.ARM-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: 250 Armlock series, CN(A) Tang Type Terminal
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7122-2137-30 (PA66), 7122-2237-30 (PP)
Natural | 6111-2556 (PA66), 6070-3381 (PP) | 7122-2137 (PA66), 7122-2237 (PP)
Mating Part: 250.ARM-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Hero B-38R (male half)
QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100-249$0.90
250-499$0.84
500+$0.77
Quantity:  Kit

3-Way Kit
250.ARM-3S
3-Way Kit
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7123-2137-30 (PA66), 7123-2237-30 (PP)
Natural | 6111-2557 (PA66), 6070-3391 (PP) | 7123-2137 (PA66), 7123-2237 (PP)
250.ARM-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: 250 Armlock series, CN(A) Tang Type Terminal
OEM P/N: Color | Sumitomo | Yazaki
Black | () | 7123-2137-30 (PA66), 7123-2237-30 (PP)
Natural | 6111-2557 (PA66), 6070-3391 (PP) | 7123-2137 (PA66), 7123-2237 (PP)
Mating Part: 250.ARM-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Hero B-38R (female half)
QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100-249$0.90
250-499$0.84
500+$0.77
Quantity:  Kit

3-Way Kit
250.HL-3P
3-Way Kit
250.HL-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: AMP/TE, Sumitomo, Yazaki
Series: 250 Housing Lance, 250 Armlock-Housing Lance, CN(A) Plastic Lock-Arm
Mating Part: 250.HL-3S

AMP/TESumitomoYazaki
172131-16070-36217122-2830
Available stock: Aftermarket OEM

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100+$0.90
Quantity:  Kit

3-Way Kit
250.HL-3S
3-Way Kit
250.HL-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: AMP/TE, Sumitomo, Yazaki
Series: 250 Housing Lance, 250 Armlock-Housing Lance, CN(A) Plastic Lock-Arm
Mating Part: 250.HL-3P

AMP/TESumitomoYazaki
172132-16070-36117123-2830
Available stock: Aftermarket OEM

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.29
6-19$1.20
20-49$1.10
50-99$1.03
100+$0.90
Quantity:  Kit

3-Way Kit
250.LOC-3P
3-Way Kit
250.LOC-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo
Series: 250 Lock series
Mating Part: 250.LOC-3S
P/N:
Natural, 6120-2033 (PP), 6010-3041 (PA66)
Black, ()

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KTM 000700000DD
QtyPrice
1-5$1.45
6-19$1.35
20-49$1.23
50-99$1.16
100+$1.01
Quantity:  Kit

3-Way Kit
250.LOC-3S
3-Way Kit
250.LOC-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo
Series: 250 Lock series
Mating Part: 250.LOC-3P
P/N:
Natural, 6110-4533 (PP)(6020-3261 w/flange)
Black, ()

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PA66
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KTM 000700000DC
QtyPrice
1-5$1.45
6-19$1.35
20-49$1.23
50-99$1.16
100+$1.01
Quantity:  Kit

3-Way Kit
250.LT-3P
3-Way Kit
OEM P/N: 6120-0533
250.LT-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: Sumitomo 250 LT Type
OEM P/N: 6120-0533
Mating Part: 250.LT-3S

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PP
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-20 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • KUM PH021-03010
  • Yazaki 7123-2030
QtyPrice
1-5$2.80
6-19$2.60
20-49$2.38
50-99$2.24
100+$1.96
Quantity:  Kit

3-Way Kit
250.LT-3S
3-Way Kit
OEM P/N: 6110-2533 (alt p/n w/flange 6110-0333)
250.LT-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts

Mfr: Aftermarket Sumitomo, Yazaki
Series: Sumitomo 250 LT Type
OEM P/N: 6110-2533 (alt p/n w/flange 6110-0333)
Mating Part: 250.LT-3P

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:4.0mm
  • Row Spacing:7.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Terminal Lance
  • Housing Material:PP
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-20 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.80
6-19$2.60
20-49$2.38
50-99$2.24
100+$1.96
Quantity:  Kit

3-Way Kit
250.WC-3P
3-Way Kit
OEM P/N: 6180-3541
250.WC-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, rear wire seal

Mfr: Aftermarket Sumitomo
Series: 250 Waterproof Connector
OEM P/N: 6180-3541
Mating Part: 250.WC-3S

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:5.5mm
  • Row Spacing:8.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:NBR
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.35
6-19$4.13
20-49$3.91
50-99$3.70
100+$3.48
Quantity:  Kit

3-Way Kit
250.WC-3S
3-Way Kit
OEM P/N: 6187-3551
250.WC-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, rear seal

Mfr: OEM Sumitomo
Series: 250 Waterproof Connector
OEM P/N: 6187-3551
Mating Part: 250.WC-3P

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.30 - 3.00 mm2
  • Number of Rows:2
  • Pitch:5.5mm
  • Row Spacing:8.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:NBR
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 120 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$5.57
6-19$5.29
20-49$5.01
50-99$4.73
100+$4.46
Quantity:  Kit

3-Way Kit
58W-3P
3-Way Kit
OEM P/N: 7122-1834-40
58W-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals, rear holder/lock

Mfr: OEM Yazaki
Series: Sumitomo: 58 W Sealed, Yazaki: 58 W Sealed
OEM P/N: 7122-1834-40
Part Name: W03MW
Mating Part: 7223-1834-40

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.8mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Mounting Style:Clip Slot
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$5.04
6-19$4.79
20-49$4.54
50-99$4.28
100+$4.03
Quantity:  Kit

3-Way Kit
58X-3P
3-Way Kit
OEM P/N: 7222-6234-40
58X-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals, rear retainer/lock

Mfr: OEM Yazaki
Series: 58 X Sealed
OEM P/N: 7222-6234-40
Part Name: X03MGY
Mating Part: 58X-3S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.50 - 3.00 mm2
  • Number of Rows:2
  • Pitch:10.4mm
  • Row Spacing:8.55mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$5.81
6-19$5.52
20-49$5.23
50-99$4.94
100+$4.65
Quantity:  Kit

3-Way Kit
58X-3S
3-Way Kit
OEM P/N: 7123-6234-40
58X-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, rear retainer/lock

Mfr: OEM Yazaki
Series: 58 X Sealed
OEM P/N: 7123-6234-40
Part Name: X03FGY
Mating Part: 58X-3P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:6.3mm (.250)
  • Wire Size:0.50 - 3.00 mm2
  • Number of Rows:2
  • Pitch:10.4mm
  • Row Spacing:8.55mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:20A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.91
6-19$4.66
20-49$4.42
50-99$4.17
100+$3.93
Quantity:  Kit

3-Way Kit
62E-3S-1
3-Way Kit
OEM P/N: 6098-0141
62E-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals (62E-SL5), lock

Mfr: OEM Sumitomo
Series: 62 E-Type
OEM P/N: 6098-0141
Part Name: E03FGY
Mating Part: N/A, device only
Superseded by RS.E-3S-1 per Sumitomo

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:20A
  • Voltage Rating:14V DC
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$5.81
6-19$5.52
20-49$5.23
50-99$4.94
100+$4.65
Quantity:  Kit

3-Way Kit
712-3P
3-Way Kit
OEM P/N: 99-0405-00-03
712-3P  3-Way Kit
Kit Contents: 1x 3-way solder cup kit

Mfr: OEM Binder
Series: 712 Series
OEM P/N: 99-0405-00-03
Mating Part: 99-0406-00-03
  • Max. 24 awg wire
  • Cable dia. 3.5-5mm (.138-.197 in)

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.13 - 0.25 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, circular
  • Termination:Solder Cup
  • Housing Material:PA
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:4A
  • Voltage Rating:125V
Environmental
  • Temp Range[2]:-40 - 85 °C
  • Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Price: $12.07
Quantity:  Kit

3-Way Kit
719-3P-x
3-Way Kit
OEM P/N: 09-9747-70-03 for cable dia. 3-4mm (.118-.157 in)
09-9747-71-03 for cable dia. 4-5mm (.157-.197 in)
719-3P-x  3-Way Kit
Kit Contents: 1x 3-way solder cup kit for max. 22 awg wire

Mfr: OEM Binder
Series: 719 Series
OEM P/N: 09-9747-70-03 for cable dia. 3-4mm (.118-.157 in)
09-9747-71-03 for cable dia. 4-5mm (.157-.197 in)
Mating Part: 719-3S-x

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:0.75mm (.030)
  • Wire Size:0.13 - 0.25 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, circular
  • Termination:Solder Cup
  • Housing Material:PA
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
  • Voltage Rating:60V
Environmental
  • Temp Range[2]:-25 - 70 °C
  • Protection Rating:IP40
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Common on 2D Debus & Diebold systems and hardware
  • Common on Aim data logger systems and hardware
Price: $6.32
Quantity:  Kit

3-Way Kit
719-3S-x
3-Way Kit
OEM P/N: 09-9748-70-03 for cable dia. 3-4mm (.118-.157 in)
09-9748-71-03 for cable dia. 4-5mm (.157-.197 in)
719-3S-x  3-Way Kit
Kit Contents: 1x 3-way solder cup kit for max. 22 awg wire

Mfr: OEM Binder
Series: 719 Series
OEM P/N: 09-9748-70-03 for cable dia. 3-4mm (.118-.157 in)
09-9748-71-03 for cable dia. 4-5mm (.157-.197 in)
Mating Part: 719-3P-x

spacer
General
  • Sealing:Unsealed
  • Number of Ways:3
  • Contact Size:0.75mm (.030)
  • Wire Size:0.13 - 0.25 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, circular
  • Termination:Solder Cup
  • Housing Material:PA
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:3A
  • Voltage Rating:60V
Environmental
  • Temp Range[2]:-25 - 70 °C
  • Protection Rating:IP40
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Common on 2D Debus & Diebold systems and hardware
  • Common on Aim data logger systems and hardware
Price: $6.04
Quantity:  Kit

3-Way Kit, Type C
APEX.28-3P-C
3-Way Kit, Type C
OEM P/N: 54200314 (Aptiv p/n: 13865701)
APEX.28-3P-C  3-Way Kit, Type C
Kit Contents: Housing, 3 pin contacts

Mfr: OEM FCI (Delphi/Aptiv)
Series: APEX 2.8 Series
OEM P/N: 54200314 (Aptiv p/n: 13865701)
Keying: C
Mating Part: APEX.28-3S-C

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 6.00 mm2
  • Number of Rows:1
  • Pitch:5.25mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:40A
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IP68
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Chrysler 56038165
QtyPrice
1-5$6.05
6-19$5.75
20-49$5.45
50-99$5.14
100+$4.84
Quantity:  Kit

3-Way Kit, Type A
APEX.28-3S-A
3-Way Kit, Type A
OEM P/N: 54200308 (Aptiv p/n: 10757671)
APEX.28-3S-A  3-Way Kit, Type A
Kit Contents: Housing, 3 socket contacts

Mfr: OEM FCI (Delphi/Aptiv)
Series: APEX 2.8 Series
OEM P/N: 54200308 (Aptiv p/n: 10757671)
Keying: A
Mating Part: 54200312

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 6.00 mm2
  • Number of Rows:1
  • Pitch:5.25mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes
Electrical
  • Current Rating[1]:40A
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IP68
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Chrysler 56038149, and connector used in Mopar 05014007AB repair kit.
  • Nissan/Bosch J-48817-1110 pigtail connector
  • Nissan service part 24008-9DK1A connector
QtyPrice
1-5$4.67
6-19$4.44
20-49$4.20
50-99$3.97
100+$3.74
Quantity:  Kit

3-Way Kit, Type B
APEX.28-3S-B
3-Way Kit, Type B
OEM P/N: 54200309 (Aptiv p/n: 15380782)
APEX.28-3S-B  3-Way Kit, Type B
Kit Contents: Housing, 3 socket contacts

Mfr: OEM FCI (Delphi/Aptiv)
Series: APEX 2.8 Series
OEM P/N: 54200309 (Aptiv p/n: 15380782)
Keying: B
Mating Part: 54200313

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 6.00 mm2
  • Number of Rows:1
  • Pitch:5.25mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes
Electrical
  • Current Rating[1]:40A
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IP68
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Chrysler 56038150, and connector used in Mopar 05014008AA repair kit.
  • Nissan/Bosch J-48817-1111 pigtail connector
  • Nissan service part 24008-9DK1B connector
QtyPrice
1-5$5.73
6-19$5.44
20-49$5.16
50-99$4.87
100+$4.58
Quantity:  Kit

3-Way Kit, Type C
APEX.28-3S-C
3-Way Kit, Type C
OEM P/N: 54200310 (Aptiv p/n: 13849913)
APEX.28-3S-C  3-Way Kit, Type C
Kit Contents: Housing, 3 socket contacts

Mfr: OEM FCI (Delphi/Aptiv)
Series: APEX 2.8 Series
OEM P/N: 54200310 (Aptiv p/n: 13849913)
Keying: C
Mating Part: APEX.28-3P-C

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 6.00 mm2
  • Number of Rows:1
  • Pitch:5.25mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes
Electrical
  • Current Rating[1]:40A
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IP68
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Chrysler 56038151, and connector used in Mopar 05014009AA repair kit.
  • Nissan/Bosch J-48817-1112 pigtail connector
  • Nissan service part 24008-9DK1C connector
QtyPrice
1-5$5.51
6-19$5.23
20-49$4.96
50-99$4.68
100+$4.41
Quantity:  Kit

3-Way Kit, Type D
APEX.28-3S-D
3-Way Kit, Type D
OEM P/N: 54200311 (Aptiv p/n: 13849911)
APEX.28-3S-D  3-Way Kit, Type D
Kit Contents: Housing, 3 socket contacts

Mfr: OEM FCI (Delphi/Aptiv)
Series: APEX 2.8 Series
OEM P/N: 54200311 (Aptiv p/n: 13849911)
Keying: D
Mating Part: 54200315 (Aptiv p/n: 33500095)

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.30 - 6.00 mm2
  • Number of Rows:1
  • Pitch:5.25mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes
Electrical
  • Current Rating[1]:40A
Environmental
  • Temp Range[2]:-40 - 150 °C
  • Protection Rating:IP68
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Chrysler 56038152, and connector used in Mopar 05014010AB repair kit.
QtyPrice
1-5$5.51
6-19$5.23
20-49$4.96
50-99$4.68
100+$4.41
Quantity:  Kit

3-Way Kit, Keying A
APEX.28SM-3S
3-Way Kit, Keying A
OEM P/N: F258300 (Aptiv p/n: 13791661)
(alt. p/n w/aqua TPA: F593500, 33513145)
(alt. p/n w/CPA: F731210, 13962796)
APEX.28SM-3S  3-Way Kit, Keying A
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM FCI (Delphi/Aptiv)
Series: APEX SensoMate 2.8 Series
OEM P/N: F258300 (Aptiv p/n: 13791661)
(alt. p/n w/aqua TPA: F593500, 33513145)
(alt. p/n w/CPA: F731210, 13962796)
Keying: A
Mating Part: N/A, Device only

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.50 - 3.00 mm2
  • Number of Rows:1
  • Pitch:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes, connector option
Electrical
  • Current Rating[1]:30A
Environmental
  • Temp Range[2]:-40 - 125 °C
  • Protection Rating:IP69K
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford AU2Z-14S411-JA, WPT-1068 (Tin plated, greased terminals) pigtail connector
  • Ford AU2Z-14S411-JB, WPT-1369 (Tin plated, greased terminals) pigtail connector
  • Ford 8U5T-14A464-GAC
QtyPrice
1-5$6.64
6-19$6.31
20-49$5.98
50-99$5.64
100+$5.31
Quantity:  Kit

3-Way Kit (-1 Red)
AS16-3S-1
3-Way Kit (-1 Red)
OEM P/N: 776429-1 for 2.18-3.67mm insulation dia. (in stock)
776523-1 for 1.30-2.54mm insulation dia.
AS16-3S-1  3-Way Kit (-1 Red)
Kit Contents: Housing, 3 socket contacts for .5-.8 mm2 (20-18 AWG) wire with 1.27-2.72mm ins. dia.

Mfr: OEM Tyco/AMP
Series: AMPSEAL 16 Series
OEM P/N: 776429-1 for 2.18-3.67mm insulation dia. (in stock)
776523-1 for 1.30-2.54mm insulation dia.
Keying: -1 Red
Mating Part: 776535-x, 776430-x

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:1.58mm (.063)
  • Wire Size:0.50 - 2.50 mm2
  • Number of Rows:1
  • Pitch:4.5mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, circular
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT+GF15
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes
Electrical
  • Current Rating[1]:16A
  • Voltage Rating:250V DC
Environmental
  • Temp Range[2]:-40 - 125 °C
  • Protection Rating:IP67
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$4.69
6-19$4.46
20-49$4.22
50-99$3.99
100+$3.75
Quantity:  Kit

4.0mm Triple Bullet Receptacle kit
BC40-3S
4.0mm Triple Bullet Receptacle kit
BC40-3S  4.0mm Triple Bullet Receptacle kit
Note: This is not classified as a sealed connector. The sleeve function is to provide electrical insulation only.

Kit Contents: 1 terminal and 1 insulator

Mating Part: Accepts 3x BC40-1P-A

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, circular
  • Termination:Open barrel crimp
  • Mounting Style:Free hanging
  • TPA:No
  • CPA:No
Electrical
  • Current Rating[1]:10A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-49$0.59
50-99$0.53
100-249$0.47
250-499$0.41
500-999$0.35
1000+$0.29
Quantity:  Kit

3-Way Kit
DL040-3S
3-Way Kit
OEM P/N: 6189-0734 (superseded by: 6189-8156)
DL040-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Sumitomo
Series: DL 040 Sealed Series
OEM P/N: 6189-0734 (superseded by: 6189-8156)
Part Name: W-04CISASY3F-GR (ss by: W-04CISASY3F2-GR)

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.0mm (.040)
  • Wire Size:0.30 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.1mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:8A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$3.47
6-19$3.30
20-49$3.12
50-99$2.95
100+$2.78
Quantity:  Kit

3-Way Kit
DL090-3P
3-Way Kit
OEM P/N: 6195-0012
DL090-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: OEM Sumitomo
Series: DL 090 Sealed Series
OEM P/N: 6195-0012
Part Name: DL09ASY3M-GR
Mating Part: DL090-3S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA6T
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$3.52
6-19$3.34
20-49$3.17
50-99$2.99
100+$2.82
Quantity:  Kit

3-Way Kit
DL090-3S
3-Way Kit
OEM P/N: 6195-0009
DL090-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Sumitomo
Series: DL 090 Sealed Series
OEM P/N: 6195-0009
Part Name: DL09ASY3F-GR
Mating Part: DL090-3P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.3mm (.090)
  • Wire Size:0.30 - 2.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA6T
  • Seal Material:NBR
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:22A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

QtyPrice
1-5$3.77
6-19$3.58
20-49$3.39
50-99$3.20
100+$3.02
Quantity:  Kit

3-Way Kit
DMS-3S-A
3-Way Kit
OEM P/N: 7283-1334-30
DMS-3S-A  3-Way Kit
Kit Contents: Housing, 3 socket contacts for 20-18 AWG wire, 3 seals for 1.6-1.8mm O.D. wire, rear TPA

Mfr: Yazaki
Series: DMS Series
OEM P/N: 7283-1334-30
Keying: A
Mating Part: N/A, device only

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:1
  • Pitch:5.3mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford F6DB-14A464-BJA
  • Ford 3U2Z-14S411-EYAA, WPT-754 (Tin plated terminals) pigtail connector
  • Ford 1U2Z-14S411-AFB, WPT-993 (Tin plated, greased terminals) pigtail connector
QtyPrice
1-5$5.08
6-19$4.83
20-49$4.57
50-99$4.32
100+$4.06
Quantity:  Kit

3-Way Kit
DMS-3S-B
3-Way Kit
OEM P/N: 7283-1333-10
DMS-3S-B  3-Way Kit
Kit Contents: Housing, 3 socket contacts for 20-18 AWG wire, 3 seals for 1.6-1.8mm O.D. wire, rear TPA

Mfr: Yazaki
Series: DMS Series
OEM P/N: 7283-1333-10
Keying: B
Mating Part: N/A, device only

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:2.8mm (.110)
  • Wire Size:0.50 - 2.00 mm2
  • Number of Rows:1
  • Pitch:5.3mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:10A
Environmental
  • Temp Range[2]:-40 - 85 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford F6DB-14A464-BKA
  • Ford 2U2Z-14S411-AC, WPT-1044 (Tin plated, greased terminals) pigtail connector
QtyPrice
1-5$5.76
6-19$5.47
20-49$5.18
50-99$4.90
100+$4.61
Quantity:  Kit

3-Way Receptacle
DT-3P GRY.N
3-Way Receptacle
DT-3P GRY.N  3-Way Receptacle

Mfr: Deutsch
Series: DT
Mating Part: DT-3S

ColorSealCapPart Number
GreyN-Seal (Std)-DT04-3P, -P004
GreyN-Seal (Std)ShortDT04-3P-E003, -EP04
GreyN-Seal (Std)LongDT04-3P-E008
GreyE-Seal-DT04-3P-C015
GreyE-SealShortDT04-3P-CE01
GreyE-SealLongDT04-3P-CE04
BlackN-Seal (Std)-DT04-3P-E004
BlackN-Seal (Std)ShortDT04-3P-E005
BlackN-Seal (Std)LongDT04-3P-EE01
BlackE-Seal-DT04-3P-CE02
BlackE-SealShortDT04-3P-CE03
BlackE-SealLongDT04-3P-CE09
Availability: In-Stock

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:Size 16
  • Wire Size:0.50 - 2.50 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Pin, circular
  • Termination:Multi-option
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:13A
  • Voltage Rating:250V (AC, DC)
Environmental
  • Temp Range[2]:-55 - 125 °C
  • Protection Rating:IP68, IP6K9K
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.60
6-19$1.52
20-49$1.44
50-99$1.36
100+$1.28
Quantity:  Ea

3-Way Plug
DT-3S GRY.N
3-Way Plug
DT-3S GRY.N  3-Way Plug

Mfr: Deutsch
Series: DT
Mating Part: DT-3P

ColorSealCapPart Number
GreyN-Seal (Std)-DT06-3S, -P004
GreyN-Seal (Std)ShortDT06-3S-E003, -EP04
GreyN-Seal (Std)LongDT06-3S-E008
GreyE-Seal-DT06-3S-C015
GreyE-SealShortDT06-3S-CE01
GreyE-SealLongDT06-3S-CE04
BlackN-Seal (Std)-DT06-3S-E004
BlackN-Seal (Std)ShortDT06-3S-E005
BlackN-Seal (Std)LongDT06-3S-EP11
BlackE-Seal-DT06-3S-CE02
BlackE-SealShortDT06-3S-CE05
BlackE-SealLongDT06-3S-CE13
Availability: In-Stock

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:Size 16
  • Wire Size:0.50 - 2.50 mm2
  • Number of Rows:N/A
  • Pitch:N/A, Circular
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Socket, circular
  • Termination:Multi-option
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:13A
  • Voltage Rating:250V (AC, DC)
Environmental
  • Temp Range[2]:-55 - 125 °C
  • Protection Rating:IP68, IP6K9K
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$1.62
6-19$1.54
20-49$1.46
50-99$1.38
100+$1.30
Quantity:  Ea

3-Way Receptacle
DTM-3P
3-Way Receptacle
DTM-3P  3-Way Receptacle

Mfr: Deutsch
Series: DTM
Mating Part: DTM-3S

ColorCapPart Number
Grey-DTM04-3P
GreyShortDTM04-3P-E003
GreyLongDTM04-3P-E007
Black-DTM04-3P-E004
BlackShortDTM04-3P-E005
BlackLongN/A
Availability: In-Stock

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:Size 20
  • Wire Size:0.22 - 2.50 mm2
  • Number of Rows:1
  • Pitch:4.2mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, circular
  • Termination:Multi-option
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:7.5A
  • Voltage Rating:250V (AC, DC)
Environmental
  • Temp Range[2]:-55 - 125 °C
  • Protection Rating:IP68, IP6K9K
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Qty% Off
6-19 5%
20-4910%
50-9915%
100+20%
Quantity:  Ea

3-Way Plug
DTM-3S
3-Way Plug
DTM-3S  3-Way Plug

Mfr: Deutsch
Series: DTM
Mating Part: DTM-3P

ColorCapPart Number
Grey-DTM06-3S
GreyShortN/A
GreyLongDTM06-3S-E007
Black-DTM06-3S-E004
BlackShortN/A
BlackLongN/A
Availability: In-Stock

spacer
General
  • Sealing:Matte Sealed
  • Number of Ways:3
  • Contact Size:Size 20
  • Wire Size:0.22 - 2.50 mm2
  • Number of Rows:1
  • Pitch:4.2mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, circular
  • Termination:Multi-option
  • Lance Type:Housing Lance
  • Housing Material:PA66+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:7.5A
  • Voltage Rating:250V (AC, DC)
Environmental
  • Temp Range[2]:-55 - 125 °C
  • Protection Rating:IP68, IP6K9K
  • Flammability Rating:UL94 V-0
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

Qty% Off
6-19 5%
20-4910%
50-9915%
100+20%
Quantity:  Ea

3-Way Kit
EPC15-3P
3-Way Kit
OEM P/N: E-5965-001
EPC15-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals

Mfr: OEM EPC
Series: 1.5mm Sealed Series
OEM P/N: E-5965-001
Mating Part: EPC15-3S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 1.25 mm2
  • Number of Rows:1
  • Pitch:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT+GF
  • Mounting Style:Clip Slot
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:15A
Environmental
  • Temp Range[2]:-40 - 145 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford 3F2T-14A624-EA
  • Ford 3F2T-14A624-CA (with CLIP-201)
QtyPrice
1-5$4.38
6-19$4.07
20-49$3.72
50-99$3.50
100+$3.29
Quantity:  Kit

3-Way Kit
EPC15-3S
3-Way Kit
OEM P/N: E-5756
EPC15-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM EPC
Series: 1.5mm Sealed Series
OEM P/N: E-5756
Mating Part: EPC15-3P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 2.00 mm2
  • Number of Rows:1
  • Pitch:5.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:15A
Environmental
  • Temp Range[2]:-40 - 145 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Ford 8U2Z-14S411-ZB, WPT-990 (Tin plated terminals, greased) pigtail connector
  • Ford 2L1T-14A464-ZA
QtyPrice
1-5$4.86
6-19$4.52
20-49$4.13
50-99$3.89
100+$3.65
Quantity:  Kit

3-Way Kit
ESJ-3P
3-Way Kit
OEM P/N: 174359-2
ESJ-3P  3-Way Kit
Kit Contents: Housing, 3 pin contacts, 3 seals, lock

Mfr: OEM Tyco/AMP
Series: Econoseal J Series Mk II
OEM P/N: 174359-2
Mating Part: ESJ-3S

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.8mm (.070)
  • Wire Size:0.20 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.8mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Pin, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Mounting Style:Free hanging
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:18.5A
  • Voltage Rating:12V DC
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Hero FRA-113N
QtyPrice
1-5$2.98
6-19$2.83
20-49$2.68
50-99$2.53
100+$2.38
Quantity:  Kit

3-Way Kit
ESJ-3S
3-Way Kit
OEM P/N: 174357-2 (superseded by: 2822390-1)
ESJ-3S  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals, lock plate

Mfr: OEM Tyco/AMP
Series: Econoseal J Series Mk II
OEM P/N: 174357-2 (superseded by: 2822390-1)
Mating Part: ESJ-3P

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.8mm (.070)
  • Wire Size:0.20 - 1.25 mm2
  • Number of Rows:1
  • Pitch:4.8mm
  • Numbered Cavities:No
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PBT
  • Seal Material:NBR
  • Mounting Style:Clip Slot
  • TPA:Yes, separate/loose item
  • CPA:No
Electrical
  • Current Rating[1]:18.5A
  • Voltage Rating:12V DC
Environmental
  • Temp Range[2]:-30 - 105 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Hero FRA-114N
  • KTM 000700000DP
QtyPrice
1-5$3.23
6-19$3.07
20-49$2.91
50-99$2.75
100+$2.58
Quantity:  Kit

3-Way Kit
FM60-3S-2
3-Way Kit
OEM P/N: ZFJ-00703-UA
FM60-3S-2  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Federal Mogul
Series: 6.0 Centerline
OEM P/N: ZFJ-00703-UA
Keying: B
Mating Part: N/A, device only

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.35 - 1.00 mm2
  • Number of Rows:1
  • Pitch:6.0mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PPE/PA+GF10
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:15A
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.

spacer
  • Ford 3S4T-14A464-DA
  • Ford 3U2Z-14S411-FHAB, WPT-1167 (Silver plated terminals) pigtail connector
QtyPrice
1-5$5.16
6-19$4.90
20-49$4.64
50-99$4.39
100+$4.13
Quantity:  Kit

3-Way Kit
GT150.35-3S-1
3-Way Kit
OEM P/N: 15336121
GT150.35-3S-1  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Delphi
Series: GT-150 3.5mm CL Sealed Series
OEM P/N: 15336121
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.30 - 1.00 mm2
  • Number of Rows:1
  • Pitch:3.5mm
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes, separate item
Electrical
  • Current Rating[1]:15A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.46
6-19$2.34
20-49$2.21
50-99$2.09
100+$1.97
Quantity:  Kit

3-Way Kit
GT150.35-3S-2
3-Way Kit
OEM P/N: 33152358 (purple lock), supersedes 15326556 (grey lock)
GT150.35-3S-2  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Delphi
Series: GT-150 3.5mm CL Sealed Series
OEM P/N: 33152358 (purple lock), supersedes 15326556 (grey lock)
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.30 - 1.00 mm2
  • Number of Rows:1
  • Pitch:3.5mm
  • Numbered Cavities:Yes, Alphabetically
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA66
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:Yes, separate item
Electrical
  • Current Rating[1]:15A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

QtyPrice
1-5$2.24
6-19$2.13
20-49$2.02
50-99$1.90
100+$1.79
Quantity:  Kit

3-Way Kit
GT150.35-3S-5
3-Way Kit
OEM P/N: 15336029
GT150.35-3S-5  3-Way Kit
Kit Contents: Housing, 3 socket contacts, 3 seals

Mfr: OEM Delphi
Series: GT-150 3.5mm CL Sealed Series
OEM P/N: 15336029
Mating Part: N/A

spacer
General
  • Sealing:Single Wire Sealed
  • Number of Ways:3
  • Contact Size:1.5mm (.060)
  • Wire Size:0.30 - 1.00 mm2
  • Number of Rows:1
  • Pitch:3.5mm
  • Numbered Cavities:Yes, Numbered
Mechanical
  • Contact Type:Socket, flat
  • Termination:Open barrel crimp
  • Lance Type:Housing Lance
  • Housing Material:PA6+GB+GF
  • Seal Material:Silicone Rubber
  • Mounting Style:Free hanging
  • TPA:Yes
  • CPA:No
Electrical
  • Current Rating[1]:15A
Environmental
  • Temp Range[2]:-40 - 125 °C
1. Current rating is for reference only, as it is typically based on a single circuit in free air, affected by conditions such as circuit count, wire size, ambient temperature, etc.
2. Temperature range is for reference only, and may/may not include temperature rise.
For detailed characteristics, see applicable product documents.

spacer
  • Harley Davidson 72064-06
QtyPrice
1-5$2.60
6-19$2.47
20-49$2.34
50-99$2.21
100+$2.08
Quantity:  Kit

180 Items.  Showing Items 1 thru 50.
 1  2  3  4   Next »   Show All

Facebook link spacer Instagram link spacer LinkedIn link spacer Twitter link spacer Twitter link
Privacy Notice | Terms and Conditions | Site Map
© 2009-2025 Corsa Technic, LLC. All Rights Reserved. All trademarks are the property of their respective owners.
R6A1
R7A4
R7A3
R7A2
